Exulus Spatial Light Modulators with WUXGA Resolution
Liquid Crystal on Silicon (LCoS) with One of Two Coatings:
1920 x 1200 (WUXGA) Resolution
HDMI*-Compatible and USB 2.0 Input Connectors
SMA Trigger Output
Optic Axis: 0°
Housing Dimensions: 155.9 mm x 104.3 mm x 42.0 mm
The EXULUS-HD2, EXULUS-HD3, and EXULUS-HD4 Spatial Light Modulators (SLMs) are designed to operate at 400 - 850 nm, 650 - 1100 nm, and 1550 nm,
respectively. Each SLM has an LCoS panel with a resolution of 1920 x 1200 in a compact housing. They also feature high phase stability and SMA trigger outputs for
synchronized applications. Two sides of the housing each offer two universal mounting holes that accept both 8-32 and M4 threads; please note that these threads
are separated by 50 mm. The front panel includes four 4-40 taps for 30 mm cage system compatibility; we do not recommend connecting these spatial light
modulators to a cage system for applications that require precise alignment.
*HDMI is a trademark or registered trademark of HDMI Licensing Administrator, Inc. The use of such trademark by Thorlabs does not constitute or imply any affiliation
with or endorsement or sponsorship by such trademark owner.
Operating
Item #
Wavelength
EXULUS-HD2 400 - 850 nm
EXULUS-HD3 650 - 1100 nm
EXULUS-HD4 1550 nm
a. Complete specifications may be found on the Specs tab.
b. Angles of incidence other than 0° will result in phase shifts that differ from the programmed pattern. Angles of up to 10° are possible without significantly
affecting performance.
c. Fluctuation / Flickering is the phase fluctuation as the percentage of the entire phase range and is dependent on the current phase setting. The value stated is
the maximum fluctuation and typically occurs at half of the phase range.
Part Number
EXULUS-HD2 Spatial Light Modulator, 1920 x 1200, 400 - 850 nm, Universal 8-32 / M4 Taps
EXULUS-HD3 Customer Inspired! Spatial Light Modulator, 1920 x 1200, 650 - 1100 nm, Universal 8-32 / M4 Taps
EXULUS-HD4 Spatial Light Modulator, 1920 x 1200, 1550 nm, Universal 8-32 / M4 Taps
Exulus Spatial Light Modulators with WUXGA Resolution, High Power
Liquid Crystal on Silicon (LCoS) with an Aluminum
Coating for
400 - 850 nm or 650 - 1100 nm
1920 x 1200 (WUXGA) Resolution
High Power Handing: ≤200 W/cm
Liquid Cooling Module Included on SLM Head
Compatible with LK220 Thermoelectric Liquid Chiller
HDMI*-Compatible and USB 2.0 Input Connectors
SMA Trigger Output
Optic Axis: 0°
Housing Dimensions:
Aluminum Coating for 400 - 850 nm (EXULUS-HD2)
Aluminum Coating for 650 - 1100 nm (EXULUS-HD3)
Dielectric Coating for 1550 nm (EXULUS-HD4)
Panel
Fill Factor Panel Active Area
Resolution
1920 x 1200
>92% 15.42 mm x 9.66 mm
(WUXGA)
All-in-One: 220.0 mm x 104.0 mm x 68.0 mm
a
Key Specifications
Phase / Retardance
Pixel Pitch
2π at 633 nm
8 µm 2π at 1064 nm
2π at 1550 nm
Description
Click to Enlarge
The High-Power SLM housing
features two 8-32 (M4 x 0.7)
taps for mounting in the all-in-
one configuration.
Click to Enlarge
The top panels of the EXULUS-HD2,
EXULUS-HD3 (shown), and EXULUS-HD4
provide HDMI-compatible and USB 2.0
ports for connecting the SLM to a PC, SMA
trigger output, power supply input, and an
Frame Rate
b
Range Flickering (RMS)
60 Hz
The adapter board and SLM head
(M4 x 0.7) threads for mounting in the
separate-panel configuration. Mounting
the SLM head in a POLARIS-K1 mirror
mount provides tip and tilt adjustments.
on/off switch.
Fluctuation/
Output
c Trigger
<0.01%
Yes
<0.05%
(SMA)
<0.15%
Price Availability
$13,302.45 Today
$16,143.75 Today
$18,845.14 Today
Click to Enlarge
include 8-32
