THORLABS EXULUS-4K1 Instructions Manual page 3

a. Complete specifications may be found on the Specs tab
b. Angles of incidence other than 0° will result in phase shifts that differ from the programmed pattern. Angles of up to 10° are possible without significantly
affecting performance.
c. Frame Boost Mode (referred to as Triple Mode in the software) plays the R, G, and B channels of the video signal in succession, for an overall frame rate
of 180 Hz.
d. These retardance ranges are achievable by setting the phase stroke mode to half wave or full wave in the software.
e. HD2HP and HD3HP phase/retardance range values are for 30 °C when used with the LK220 liquid chiller.
S P E C S
Item #
Panel Resolution
Type
Operating Wavelength
Panel Active Area
Pixel Pitch
Fill Factor
Reflective Coating
Average Reflectance
Phase / Retardance Range
a
Angle of Incidence
Optic Axis
Reflected Wavefront Distortion
CW
Damage Threshold Pulsed (ns)
Pulsed (fs)
Frame Rate
Fluctuation / Flickering (RMS)
Beam Deviation Using Panel Tip / Tilt
e
Trigger Output
Trigger Output High Voltage Level
Trigger Output Pulse Width
f
Dimensions (L x W x H)
Weight
Storage Temperature
g
Operating Temperature
PC Connection
Bit Depth
a. Other angles of incidence will result in phase shifts that differ from the programmed pattern. Angles of up to 10°
are possible without significantly affecting performance.
b. The power density of your beam should be calculated in terms of W/cm. For an explanation of why the linear
power density provides the best metric for long pulse and CW sources, please see the Damage Thresholds tab.
c. Frame Boost Mode (referred to as Triple Mode in the software) plays the R,G, and B channels of the video signal
in succession, for an overall frame rate of 180 Hz.
d. Fluctuation / Flickering is the phase fluctuation as the percentage of the entire phase range and is dependent on
current phase setting. The value stated is the maximum fluctuation and typically occurs at half of the phase range.
e. For more details on the external trigger output, please refer to the product manuals accessible through the red
Docs ( ) icons below.
f. The reported height dimension includes the maximum travel range of the adjuster knob.
g. Ambient temperature fluctuations may cause the characteristics of your SLM to change. Using it at an ambient
temperature of 25 °C is recommended.
Liquid Crystal on Silicon (LCoS) with Reflective Coating
2π at 633 nm (Standard Mode); 4.7π at 532 nm (Extended Mode)
b 5 W/cm (532 nm, Ø0.0107 mm)
0.63 J/cm
0.138 J/cm
60 Hz (Standard Mode); 180 Hz (Frame Boost/Triple
d <1% (Standard Mode); <5% (Extended Mode)
172.0 mm x 110.0 mm x 81.6 mm (6.77" x 4.33" x 3.21")
0 °C to 60 °C (32 °F to 140 °F)
10 °C to 40 °C (50 °F to 104 °F)
EXULUS-HD1(/M)
1920 x 1080 (Full HD)
400 - 850 nm
12.5 mm x 7.1 mm
6.4 µm
>93%
Aluminum
75% (Typical)
0°
45°
<λ/7 @ 633 nm
2
(532 nm, 8.6 ns, 10 Hz, Ø203 µm)
2
(535 nm, 59.4 fs, 100 Hz, Ø188 µm)
±3.2°
None
N/A
N/A
1.24 kg (2.73 lbs)
HDMI-Compatible Connector
USB 2.0 Connector
8 Bit, 0 - 255 Gray Level
c
)
