Page 19: Parts And Assembly
PC-802B COUNTING SCALE 10 lb / 5 kg cap. , 12” x 14” BASE PARTS ASSEMBLY ITEM DESCRIPTION W-T P/N Remote Display Cable Assy 1140-11832 Shroud (10 lb.) 1076-15929 Quartzell Assy 7153-15694-05 Quartzell EPROM (not shown) 50705-0078 Screw, #10-32 x .25"L 1006-09173 Vinyl Cap 1051-13968... - Page 20 PC-802B COUNTING SCALE DRAFT SHIELD (10 lb. / 5 kg. 12” x 14” BASE VERSION ONLY) PARTS ASSEMBLY ITEM DESCRIPTION W-T P/N SUPPORT POST 1058-15413 SHIELD DOOR 1069-15404 SHIELD TOP PANEL 1069-15403 SHIELD REAR PANEL 1069-15406 SHIELD SIDE PANEL 1069-14604 SUPPORT POST w/SIDE HOLE 1058-14424 THREADED SPRING / PLUNGER...
- Page 21 PC-802B COUNTING SCALE 50 lb / 25 kg , 100 lb / 50 kg cap. , 12” x 14” BASE PARTS ASSEMBLY ITEM DESCRIPTION W-T P/N Remote Display Cable Assy 1140-11832 Shroud (dished) 1076-14741 Quartzell Assy (50lb / 25kg cap.) 7153-15694-32 Quartzell Assy (100lb / 50kg cap.) 7153-15694-50...
- Page 22 PC-802B COUNTING SCALE SYSTEM WIRING BLOCK DIAGRAM...
- Page 23 PC-802B COUNTING SCALE MAIN P.C. BOARD / DISPLAY BD. / KEYPAD OVERLAY...
- Page 24 PC-802B COUNTING SCALE BATTERY INSTALLATION (Battery Kit P/N 29676-0010)
- Page 25 PC-802B COUNTING SCALE SCALES BASES DIMENSIONAL OUTLINE 12” x 14” BASE...
- Page 26 PC-802B COUNTING SCALE BATTERY CHARGER (optional) PARTS LIST ITEM DESCRIPTION W-T P/N Battery Charger PC BD Assy 50093-0011 Base Plate Assy 45911-0045 Grommet 15347-0018 Standoff, M/Fem, #6 x 7/8” L 15437-0472 Screw,#6 x 3/8” L 14473-0249 Lock Washer, #6 14474-0032 Screw,#4 x 1/4”...
- Page 27 PC-802B COUNTING SCALE WALL-MOUNT BRACKET AND REMOTE TOWER (optional) PARTS AND ASSEMBLY ITEM DESCRIPTION W-T P/N Tower Support Channel 49658-0010 Tower Support Channel 49658-0028 Screw,#6 x 3/8” L 14473-0249 Grommet 15347-0018 Tower Channel (9”) 49659-0019 Tower Channel (18”) 49659-0027 Screw,#10 x ½” L 14473-0496 Tower Base 50085-0011...
- Page 28 Quartzell ® is a registered trademark of Weigh-Tronix Inc. 03/15/01 802_S.P65 PN 29721-0015e2 Printed in USA...
