  • Page 1 Quick Installation Guide IAM-5SE1004IUP Industrial Gigabit Switch Learn more about eneo IN series on our YouTube channel.
  • Page 3: Table Of Contents

    TABLE OF CONTENT Safety Instructions �����������������������������������������������������������������������������������������������������������������4 Prior to Use������������������������������������������������������������������������������������������������������������������������������7 Dimensions (in mm) & Specifications�����������������������������������������������������������������������������������������������������������������������������������������7 Parts supplied ����������������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 Product overview �������������������������������������������������������������������������������������������������������������������8...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS General • Before switching on and operating the system, first read this safety advice and the operating instructions� • Keep the operating instructions in a safe place for later use� • Installation, commissioning and maintenance of the system may only be carried out by authorised individu- als and in accordance with the installation instructions - ensuring that all applicable standards and guidelines are followed�...
  • Page 5 Product specific • Power on the system only after confirming that the wiring is correct, to avoid damage to the equipment� It is recommended to use the power adapter and power cable in the package to connect the power supply� •...
  • Page 6 WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems)� This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life�...
  • Page 7: Prior To Use

    PRIOR TO USE • Mount the junction box on a load-bearing structure such as a concrete wall� • When mounting the bracket, use the accessories supplied depending on the mounting position� Dimensions (in mm) & Specifications Construction: Metal shell Dimensions(mm): 160,00 x 110,00 x 44,00 Weight: 590,00 g (1�30 lb)
  • Page 8: Product Overview

    PRODUCT OVERVIEW The product is Industrial 4-Port Gigabit PoE++ 1-Port Gigabit RJ-45 1-Port Gigabit SFP Un- managed Ethernet Switch� The switches provide 4*10/100/1000Mbps Ethernet RJ-45 ports, 1*10/100/1000Mbps Eth- ernet RJ-45 uplink port, 1*1000Mbps SFP uplink port� It meets IEEE 802�3af/at/bt standard� Uplink RJ-45 port supportsup to 90W PoE++ power input�...
  • Page 9 Appearance Front Panel Side Panel...
  • Page 10 INSTALLATION 1� Before installation, power off the equipment� Installation when device is powered on is prohibited� 2� The switch supports DIN-rail/Desktop/Wall mounted installation� Following with the DIN-rail installation steps: Step A: Step B: Fix the bracket to the backside of the device Install the device to the DIN rail�...
  • Page 11 INHALTSVERZEICHNIS Sicherheitshinweise �������������������������������������������������������������������������������������������������������������14 Vor dem Gebrauch����������������������������������������������������������������������������������������������������������������17 Abmessungen (in mm) & Spezifikationen ����������������������������������������������������������������������������������������������������������������������������� 17 Lieferumfang��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 17 Produktübersicht������������������������������������������������������������������������������������������������������������������18 Installation ����������������������������������������������������������������������������������������������������������������������������20...
  • Page 12: Sicherheitshinweise

    SICHERHEITSHINWEISE Allgemein • Bevor Sie das System anschließen und in Betrieb nehmen, lesen Sie zuerst diese Sicherheitshinweise und die Betriebsanleitung� • Bewahren Sie die Betriebsanleitung sorgfältig zur späteren Verwendung auf� • Montage, Inbetriebnahme und Wartung des Systems darf nur durch dafür autorisierte Personen vorgenom- men und entsprechend den Installationsanweisungen - unter Beachtung aller mitgeltenden Normen und Richtlinien - durchgeführt werden�...
  • Page 13 Produktspezifisch • Schalten Sie das System erst ein, nachdem Sie sich vergewissert haben, dass die Verkabelung korrekt ist, um Schäden am Gerät zu vermeiden� Es wird empfohlen, den mitgelieferten Netzadapter und das Netzkabel für den Anschluss der Stromversorgung zu verwenden� •...
  • Page 14 WEEE-Richtlinie (Elektro- und Elektronik-Altgeräte) Ordnungsgemäße Entsorgung dieses Produkts (Gilt für die Europäische Union und die anderen Europäischen Länder mit getrennten Sammelsystemen) Dieses am Produkt oder in seiner Dokumentation gezeigte Symbol bedeutet, dass es am Ende seiner Lebensdauer nicht mit dem Hausmüll entsorgt werden darf� Um eventuelle Umwelt- oder Gesund- heitsschäden durch unkontrollierte Abfallbeseitigung zu verhindern, dieses Gerät von anderen Ab- fallarten trennen und ordnungsgemäß...
  • Page 15: Vor Dem Gebrauch

    VOR DEM GEBRAUCH • Die Anschlussbox an einer tragfähigen Struktur wie z� B� einer Betonwand befestigen� • Verwenden Sie bei der Montage der Halterung je nach Montageposition das mitgelieferte Zubehör Abmessungen (in mm) & Spezifikationen Ausführung: Metallgehäuse Abmessungen(mm): 160,00 x 110,00 x 44,00 Gewicht: 590,00 g Lieferumfang...
  • Page 16: Produktübersicht

    PRODUKTÜBERSICHT Das Produkt ist ein industrieller 4-Port Gigabit PoE++ 1-Port Gigabit RJ-45 1-Port Gigabit SFP Unmanaged Ethernet Switch� Die Switches bieten 4*10/100/1000Mbps Ethernet RJ-45 Ports, 1*10/100/1000Mbps Ethernet RJ-45 Uplink Port, 1*1000Mbps SFP Uplink Port� Er erfüllt die Norm IEEE 802�3af/at/bt� Uplink RJ-45 Port unterstützt bis zu 90W PoE++ Stromzufuhr�...
  • Page 17 Erscheinungsbild Front Seite...
  • Page 18: Installation

    INSTALLATION 1� Schalten Sie das Gerät vor der Installation aus� Die Installation bei eingeschaltetem Gerät ist verboten� 2� Der Schalter kann auf einer DIN-Schiene, auf dem Tisch oder an der Wand mon- tiert werden� Folgen Sie den Schritten für die Installation auf der DIN-Schiene: Schritt A: Schritt B: Befestigen Sie die Halterung mit Schrauben...
  • Page 19 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
