Quick Installation Guide
Industrial Gigabit Switch,
Managed, 4x PoE, 2x RJ45, 2x SFP
Learn more about eneo IN series
on our YouTube channel.
IAM-5SG1008MMC
EN
DE

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IAM-5SG1008MMC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Eneo IAM-5SG1008MMC

  • Page 1 Quick Installation Guide IAM-5SG1008MMC Industrial Gigabit Switch, Managed, 4x PoE, 2x RJ45, 2x SFP Learn more about eneo IN series on our YouTube channel.
  • Page 3: Table Of Contents

    TABLE OF CONTENT SAFETY INSTRUCTIONS ��������������������������������������������������������������������������������������������������������4 PRIOR TO USE �������������������������������������������������������������������������������������������������������������������������7 Dimensions & Specifications �������������������������������������������������������������������������������������������������������������������������������������������������7 Parts supplied �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 APPEARANCE �������������������������������������������������������������������������������������������������������������������������8 INSTALLATION ����������������������������������������������������������������������������������������������������������������������10...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Read the safety instructions and the operating instructions carefully before installing the product� Depending on the product type, individual points may be omitted� Mounting & Installation • Ensure that the intended mounting location is suitable for the respective product (e�g� in terms of weight)�...
  • Page 5: Operation

    Security • Use strong passwords for all cameras and devices to prevent unauthorized access� • Keep device firmware up to date to minimize security vulnerabilities� • Protect (remote) access to the devices using secure methods such as encrypted connections or VPN� Operation •...
  • Page 6: Graphical Symbols

    WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems)� This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life�...
  • Page 7: Prior To Use

    PRIOR TO USE • The equipment is intended to be grounded to comply with emission and immunity requirements� Ensure that the switch functional ground screw is connected to earth ground during normal use� Dimensions & Specifications Construction: Metal shell Dimensions(mm): 163,00 x 110,50 x 46,50 Weight: 820,00 g (1�81 lb)
  • Page 8: Appearance

    APPEARANCE This product is Industrial 4-Port Gigabit PoE++ 4-Port Gigabit PoE+ 2-Port 10G SFP+ 2-Port 1G/2�5G SFP L2 Managed Ethernet Switch� This switch provides 8 Gigabit Ethernet RJ-45 ports, 2*10G SFP+ ports and 2*1G/2�5G SFP ports� It meets IEEE 802�3af/at/bt standard� All RJ-45 ports support Power-over-Ethernet, 1~4 ports deliver up to 90W (PoE++) power per port, 5~8 ports deliver up to 30W (PoE+) power per port�...
  • Page 9: Front Panel

    Front Panel Gigabit SFP Port Relay Alarm Indicator 10G SFP+ ports Power Indicator SFP Indicator Gigabit Ethernet Ports LED Indicators Indicators Descriptions The power is on� P1, P2 Power Indicator The power is off� Green SFP is linked� X1~X4 SFP Indicator SFP is not linked�...
  • Page 10: Installation

    INSTALLATION The switch supports DIN-rail installation� The DIN-rail hanger is fixed on the switch at the factory� Please install the switch to the DIN rail directly� DIN-rail Mounting Grounding & Power Supply Use one end of GND cable to connect the M3 grounding connector of the switch, the other end to a ground point�...
  • Page 13 INHALTSVERZEICHNIS SICHERHEITSHINWEISE �������������������������������������������������������������������������������������������������������14 VOR DEM GEBRAUCH ����������������������������������������������������������������������������������������������������������17 Abmessungen & Spezifikationen ������������������������������������������������������������������������������������������������������������������������������������� 17 Lieferumfang ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 17 ERSCHEINUNGSBILD �����������������������������������������������������������������������������������������������������������18 INSTALLATION ����������������������������������������������������������������������������������������������������������������������20...
  • Page 14: Sicherheitshinweise

    SICHERHEITSHINWEISE Lesen Sie die Sicherheitshinweise und die Bedienungsanleitung vor der Installation des Produkts sorgfältig durch� Je nach Produkttyp können einzelne Punkte entfallen� Montage & Installation • Stellen Sie sicher, dass der vorgesehene Montageort für das jeweilige Produkt geeignet ist (z�B� hinsichtlich Gewicht)�...
  • Page 15: Betrieb

    Betrieb • Die Geräte dürfen nur innerhalb der im Datenblatt angegebenen Temperatur- und Feuchtebereiche betrieben werden� • Zur Vermeidung von Überhitzung ist für ausreichende Belüftung zu sorgen� Dies gilt insbesondere für Geräte wie Recorder und Switches, die Wärme erzeugen können� •...
  • Page 16 WEEE-Richtlinie (Elektro- und Elektronik-Altgeräte) Ordnungsgemäße Entsorgung dieses Produkts (Gilt für die Europäische Union und die anderen Europäischen Länder mit getrennten Sammelsystemen) Dieses am Produkt oder in seiner Dokumentation gezeigte Symbol bedeutet, dass es am Ende seiner Lebensdauer nicht mit dem Hausmüll entsorgt werden darf� Um eventuelle Umwelt- oder Gesund- heitsschäden durch unkontrollierte Abfallbeseitigung zu verhindern, dieses Gerät von anderen Ab- fallarten trennen und ordnungsgemäß...
  • Page 17: Vor Dem Gebrauch

    VOR DEM GEBRAUCH • Das Gerät muss geerdet werden, um die Emissions- und Störfestigkeitsanforderungen zu erfüllen� Stellen Sie sicher, dass die Funktionserdungsschraube des Switches bei normalem Gebrauch mit der Erde verbunden ist� Abmessungen & Spezifikationen Ausführung: Metallgehäuse Abmessungen(mm): 163,00 x 110,50 x 46,50 Gewicht: 820,00 g Lieferumfang...
  • Page 18: Erscheinungsbild

    ERSCHEINUNGSBILD Dieses Produkt ist ein industrieller 4-Port Gigabit PoE++ 4-Port Gigabit PoE+ 2-Port 10G SFP+ 2-Port 1G/2�5G SFP L2 Managed Ethernet Switch� Dieser Switch bietet 8 Gigabit Ethernet RJ-45 Ports, 2*10G SFP+ Ports und 2*1G/2�5G SFP Ports� Er erfüllt den Standard IEEE 802�3af/at/bt� Alle RJ-45 Ports unterstützen Power-over-Ethernet, 1~4 Ports liefern bis zu 90W (PoE++) Leistung pro Port, 5~8 Ports liefern bis zu 30W (PoE+) Leistung pro Port�...
  • Page 19 Front Panel Gigabit SFP Port Relais-Alarm Indikator 10G SFP+ Ports Stromanzeige SFP Indikator Gigabit Ethernet Ports LED Indikatoren Indicatoren Beschreibung Das Gerät ist eingeschaltet� P1, P2 Power Indikator Das Gerät ist ausgeschaltet� Grün SFP ist verbunden� X1~X4 SFP Indikator SFP ist nicht verbunden� Konsolenanschluss Das Gerät verfügt über eine RJ-45-Schnittstelle als Konsolenanschluss für die lokale Ver- waltungsschnittstelle�...
  • Page 20: Installation

    INSTALLATION Der Switch unterstützt die Montage auf DIN-Schienen� Die DIN-Schienenaufhängung ist werksseitig am Switch angebracht� Bitte installieren Sie den Switch direkt auf der DIN-Schiene� DIN-Schienenmontage Erdung & Stromversorgung Schließen Sie ein Ende des GND-Kabels an den M3-Erdungsanschluss des Switches an, das andere Ende an einen Erdungspunkt�...
  • Page 24 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
