Quick Installation Guide
Learn more about eneo IN series
on our YouTube channel.
IAD-5SG1004MUC
Gigabit Switch,
Unmanaged, 60W,
4x PoE, 1x RJ45, 1x SFP,
10/100/1000 Mbps,
EN
DE
Desktop

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IAD-5SG1004MUC and is the answer not in the manual?

Questions and answers

Summary of Contents for Eneo IAD-5SG1004MUC

  • Page 1 Quick Installation Guide IAD-5SG1004MUC Gigabit Switch, Unmanaged, 60W, 4x PoE, 1x RJ45, 1x SFP, 10/100/1000 Mbps, Desktop Learn more about eneo IN series on our YouTube channel.
  • Page 3: Table Of Contents

    TABLE OF CONTENT SAFETY INSTRUCTIONS ��������������������������������������������������������������������������������������������������������4 PRIOR TO USE �������������������������������������������������������������������������������������������������������������������������7 Dimensions & Specifications �������������������������������������������������������������������������������������������������������������������������������������������������7 Parts supplied �����������������������������������������������������������������������������������������������������������������������������������������������������������������������������7 APPLICATION ������������������������������������������������������������������������������������������������������������������������� 8 APPEARANCE �������������������������������������������������������������������������������������������������������������������������9 INSTALLATION ����������������������������������������������������������������������������������������������������������������������11...
  • Page 4: Safety Instructions

    SAFETY INSTRUCTIONS Read the safety instructions and the operating instructions carefully before installing the product� Depending on the product type, individual points may be omitted� Mounting & Installation • Ensure that the intended mounting location is suitable for the respective product (e�g� in terms of weight)�...
  • Page 5 Security • Use strong passwords for all cameras and devices to prevent unauthorized access� • Keep device firmware up to date to minimize security vulnerabilities� • Protect (remote) access to the devices using secure methods such as encrypted connections or VPN� Operation •...
  • Page 6 WEEE (Waste Electronical & Electronic Equipment) Correct Disposal of This Product (Applicable in the European Union and other European countries with separate collection systems)� This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life�...
  • Page 7: Prior To Use

    PRIOR TO USE • Transmission distance is related to the connecting cable� We suggest to use standard Cat5e/6 network cable to get 150m transmission distance� • If using optical port, customer need to purchase SFP module additional� Dimensions & Specifications Construction: Metal shell Dimensions(mm):...
  • Page 8: Application

    APPLICATION Fiber transceiver fiber 4 port PoE switch Cat 5e/6 network cable PoE IP camera PoE PTZ camera PoE Dome camera PoE Dome camera...
  • Page 9: Appearance

    APPEARANCE IAD-5SG1004MUC is a 4-Port Gigabit PoE Switch� The switch provides 4*10/100/1000Base-T PoE downlink Ethernet RJ-45 ports, 1*10/100/1000Base-T uplink Ethernet RJ-45 port and 1*1000Base-X uplink SFP port� The switch supports one key smart CCTV mode� Under CCTVmode, it supports PoE watchdog feature, which can detect and restart the camera automatically if it’s frozen�...
  • Page 10 Indicators Descriptions The power is on� Power Power Indicator The power is off� CCTV mode is on� CCTV CCTV Indicator CCTV mode is off� On(Orange) The port is supplying PoE normally� PoE1~4 Port PoE Indicator The port stops supplying PoE� On(Green) The port is linking normally�...
  • Page 11: Installation

    INSTALLATION 1� Before installation, please disconnect the power supply of each signal source and equipment� Live installation may damage the transmission equipment� 2� The switch supports desktop and wall-mounted installations� Users can place it on a clean, stable, grounded workbench, or install it on the vertical, stable wall� Wall Mounting Step 1: Fix the two hangers to the switch using the provided screws�...
  • Page 13 INHALTSVERZEICHNIS SICHERHEITSHINWEISE �������������������������������������������������������������������������������������������������������14 VOR DEM GEBRAUCH ����������������������������������������������������������������������������������������������������������17 Abmessungen & Spezifikationen ������������������������������������������������������������������������������������������������������������������������������������� 17 Lieferumfang ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 17 ANSCHLUSS ��������������������������������������������������������������������������������������������������������������������������18 ERSCHEINUNGSBILD �����������������������������������������������������������������������������������������������������������19 INSTALLATION ����������������������������������������������������������������������������������������������������������������������21...
  • Page 14: Sicherheitshinweise

    SICHERHEITSHINWEISE Lesen Sie die Sicherheitshinweise und die Bedienungsanleitung vor der Installation des Produkts sorgfältig durch� Je nach Produkttyp können einzelne Punkte entfallen� Montage & Installation • Stellen Sie sicher, dass der vorgesehene Montageort für das jeweilige Produkt geeignet ist (z�B� hinsichtlich Gewicht)�...
  • Page 15 Betrieb • Die Geräte dürfen nur innerhalb der im Datenblatt angegebenen Temperatur- und Feuchtebereiche betrieben werden� • Zur Vermeidung von Überhitzung ist für ausreichende Belüftung zu sorgen� Dies gilt insbesondere für Geräte wie Recorder und Switches, die Wärme erzeugen können� •...
  • Page 16 WEEE-Richtlinie (Elektro- und Elektronik-Altgeräte) Ordnungsgemäße Entsorgung dieses Produkts (Gilt für die Europäische Union und die anderen Europäischen Länder mit getrennten Sammelsystemen) Dieses am Produkt oder in seiner Dokumentation gezeigte Symbol bedeutet, dass es am Ende seiner Lebensdauer nicht mit dem Hausmüll entsorgt werden darf� Um eventuelle Umwelt- oder Gesund- heitsschäden durch unkontrollierte Abfallbeseitigung zu verhindern, dieses Gerät von anderen Ab- fallarten trennen und ordnungsgemäß...
  • Page 17: Vor Dem Gebrauch

    VOR DEM GEBRAUCH • Die Übertragungsdistanz hängt vom Verbindungskabel ab� Wir empfehlen die Verwendung eines Standard Cat5e/6 Netzwerkkabels, um eine Übertragungsdistanz von 150m zu erreichen� • Bei Verwendung eines optischen Anschlusses muss der Kunde zusätzlich ein SFP-Modul erwerben� Abmessungen & Spezifikationen Ausführung: Metallgehäuse Abmessungen(mm):...
  • Page 18: Anschluss

    ANSCHLUSS Glasfaser Transceiver Glasfaser 4 Port PoE Switch Cat 5e/6 Netzwerkkabel PoE IP Kamera PoE PTZ Kamera PoE Dome Kamera PoE Dome Kamera...
  • Page 19: Erscheinungsbild

    ERSCHEINUNGSBILD IAD-5SG1004MUC ist ein 4-Port Gigabit PoE Switch� Der Switch bietet 4*10/100/1000Base-T PoE Downlink Ethernet RJ-45 Ports, 1*10/100/1000Base-T Uplink Ethernet RJ-45 Port und 1*1000Base-X Uplink SFP Port� Der Switch unterstützt einen intelligenten CCTV-Modus mit einer Taste� Im CCTV-Modus unterstützt er die PoE-Watchdog-Funktion, die die Kamera automatisch erkennen und neu starten kann, wenn sie eingefroren ist�...
  • Page 20 Indikatoren Beschreibungen Das Gerät ist eingeschaltet� Power Power Indikator Das Gerät ist ausgeschaltet� Der CCTV-Modus ist aktiviert� CCTV CCTV Indikator Der CCTV-Modus ist deaktiviert� An(Orange) Der Port liefert normal PoE� PoE1~4 Port PoE Indikator Der Port liefert kein PoE� An(Grün) Der Port ist normal verbunden�...
  • Page 21: Installation

    INSTALLATION 1� Trennen Sie vor der Installation die Stromzufuhr aller Signalquellen und Geräte� Eine Installation unter Spannung kann die Übertragungsgeräte beschädigen� 2� Der Switch kann sowohl auf dem Tisch als auch an der Wand montiert werden� Sie können ihn auf einer sauberen, stabilen und geerdeten Werkbank aufstellen oder ihn an einer senkrechten, soliden Wand installieren�...
  • Page 24 Videor E. Hartig GmbH Exclusive distribution through specialised trade channels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark / Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
