- Page 1 Quick Installation Guide Gigabit Switch, Managed, Layer 3, PoE, SFP 10G, Industrie Design IAM-6SE1008IMA IAM-5SE1016IMA...
- Page 2 About this document This document is Quick Installation Guide. It is intended for engineers or anyone who needs to install the product. Announcement The information in this document is subject to change without notice. The document is only used as operation guide, except for other promises. No warranties of any kind, either express or implied are made in relation to the description, information or suggestion or any other contents of the manual.
-
Page 3: Table Of Contents
Content Packing List .................... 1 Product Introduction ................2 Overview ..................2 Hardware Introduction ..............2 Safety Precaution ................. 6 Insatallation Steps ................ 8 3.2.1 DIN-rail Installation ............... 9 3.2.2 Wall-mounted Installation ............. 10 3.2.3 DC Power Cable Connection ............11... -
Page 4: Packing List
Packing List Open the box of the product and carefully unpack it. The box should contain the following items. Please check before installation, if any missing, please contact your dealer immediately. Items Quantity Switch 1 pcs Mounting Accessory 1 set Quick Installation Guide 1 pcs... -
Page 5: Product Introduction
Product Introduction 2.1 Overview This series product is Industrial 8-Port/16-Port Gigabit PoE + 4-Port 10G SFP+ L3 Managed Ethernet Switch. This series switch provides 8/16 Gigabit Ethernet RJ-45 ports and 4 10G SFP+ fiber uplink ports. All RJ-45 ports support Power-over-Ethernet (PoE+) and deliver up to 30W power per port. - Page 6 Front Panel (16-Port PoE Switch) Left Side Panel (8-Port/16-Port PoE Switch) Led Indicators Instructions Indicators Status Descriptions The main power supply is working. DC Power Supply PWR1 Indicator (Main) The main power supply is off. The redundant power supply is DC Power Supply working.
- Page 7 System Working Blink System is working normally. Indicator On/Off System failure The device alarms. Relay Alarm Indicator The device is working normally. The port is linking normally. The port is transmitting or receiving Link Port Link Indicator Blink data. The port links down. The port is supplying PoE normally.
- Page 8 The “Relay Interface” could be connected with warner device, such as a buzzer. In the following three cases, the switch will alarm and the ALM Indicator will turn red. Alarm cases Descriptions Indicators The main power supply or backup power supply is off.
-
Page 9: Safety Precaution
Installations 3.1 Safety Precaution To minimize the technically residual risk, it is imperative to obey the following rules. Read all the instructions before operation. The Caution, Warning and Danger items in the document does not cover all the safety precautions that must be followed. They are only supplementary information. When operating the device, obey the local safety regulations. - Page 10 Inflammable Environment DANGER Do not place the device in the environment that has inflammable and explosive air or fog. Do not perform any operation in this environment. Operating the electrical device in inflammable environment can be fatal. Moisture Proof WARNING Water or moisture in the equipment will damage the circuit of the equipment.
-
Page 11: Insatallation Steps
3.2 Insatallation Steps This series switches support 2 installation methods: DIN-rail installation Wall mounted installation Following with the dimensions of the switches and its insatallation accessories. Dimensions (mm) -
Page 12: Din-Rail Installation
3.2.1 DIN-rail Installation Please follow the steps below. Step 1: Fix the DIN-rail hanger to the switch. Accessories Step 2: Install the switch to the DIN rail. Accessories Null... -
Page 13: Wall-Mounted Installation
3.2.2 Wall-mounted Installation Please follow the steps below. Step 1: Fix the hangers to the switch. Accessories Step 2: Drill 4 holes on the wall where device is installed, Accessories the diameter of the holes and distances between them are suggested as the figure below. -
Page 14: Dc Power Cable Connection
3.2.3 DC Power Cable Connection There are two ways for the switch to connect the DC power. Through terminal block. Connect with power adapter of DIN rail power supply. The installation processes are as follows. Before installation, ensure that the device is disconnected from the power supply. ... - Page 15 Turn on the DC power, and check if power supply indicator of power 1 or power 1 turns on, which means the main power (Power 1) or backup power (Power 2) is connected correctly. CAUTION For better transmission performance, it is recommended to use Cat5 or better cables to connect the switch and powered devices.
- Page 16 Specifications Items 8 ports PoE Switch 16 ports PoE Switch Ethernet Ports 16* 10/100/1000 Base-T 8* 10/100/1000 Base-T PoE Copper Ports PoE RJ-45 (Auto-MDI/MDI- RJ-45 (Auto-MDI/MDI-X) SFP Ports 4*1000/10G Base-X SFP Console Port 1*RJ-45 to RS-232 console port (115200,8,N,1) PoE Standard IEEE 802.3af/at (PSE) PSE Type End-span...
- Page 17 MTBF Standards Telcordia SR-332, 25℃ Work Temperature -40~75℃ Storage -40~85℃ Temperature Humidity 5%~95% (Non-condensation) Physical Parameters 2* power supply indicators Led Indicators 1* system working indicator 1* alarm indicator Short press to restart Init Button Long press 5s to initialize the system Dimension(W*D*H) 163mm*110mm*95.6mm Gross Weight...
