OWNER'S MANUAL
M-9630/L
ELLIPTICAL FENX
OWNER'S MANUAL V062023 ENGLISH
M-9630/L ELLIPTICAL FENX
This manual can be downloaded on www.salter.es

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FENX M-9630/L and is the answer not in the manual?

Questions and answers

Related Manuals for Salter FENX M-9630/L

Summary of Contents for Salter FENX M-9630/L

  • Page 1 OWNER’S MANUAL M-9630/L ELLIPTICAL FENX OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 2: Safety Instructions

    21. Make sure that adequate space is available for access to and passage around the equipment; keep at least a distance of 1 meter from any obstruction object while using the machine. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 3: Before You

    2. BEFORE YOU BEGIN” Thank you for choosing this SALTER equipment. We Too often, our busy lifestyles limit our time and take great pride in producing this quality product and opportunity to exercise. The Elliptical Trainer provides hope it will provide many hours of quality exercise to...

  • Page 4: Hardware Identification

    145 Bolt, Hex Head (M10xp1.5x85mm) 2pcs 127 Screw (M5xp0.8x15mm) 29 pcs 131 Bolt, Socket Head (M8xp1.25x15mm) 8pcs 158 Nut Cap (M8) 1pcs 142 Bolt(M10xp1.5x20mm) 2 pcs OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 5: Assembly Parts

    Front and Rear Stabilizer (46) Cover (77 & 78) (88 & 91) Screw Cap (153) & Back Console Tube (151) Main Frame (1) Console Case (152) OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 6 Attach the Front Stabilizer (88) onto the position as the drawing 2 shown. Main Frame (1) and secure with 2pcs Washers (8x38x2.0t)(104), 2pcs Lock Washers (M8)(100) and 2pcs Bolts (M8Xp1.25x60mm)(139). OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 7 First fully secure with 2pcs Hex Flange Bolts (M10xp1.5x20mm)(142) at the front of the Upright Post (46). Then go back to fully tighten with 2pcs Nylon Nuts (M10)(114). OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 8 Repeat the above same procedure on the left side. NOTE: Make sure the bolts and nuts are fully tightened before moving to the next step. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 9 STEP 7 – Stationary Handlebar Assembly Attach the Stationary Handlebar (38) to the Upright Post (46) and fully tighten with 4pcs Hex Head Flange Bolts (M8xp1.25x16mm)(141). OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 10 Make sure the Console Tube (151) is in the center of the Handlebar and then fully tighten 2pcs Hex Head Flange Bolts (M8xp1.25x16mm)(141) as the drawing shown below. NOTE: Be careful not to pinch the wires. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 11 Follow the drawing line, continue fully tighten 1pcs Hex Flange Bolt (M8xp1.25x16mm)(141) to the bottom of the Console Tube (151). Then press the Nut Cap (158) onto. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 12 Attach the Back Console Cover (152) to the Console (36) an fully tighten with 4pcs Self-Tapping Screws (M4x32mm)(123). b. Then press 4pcs Screw Caps (153) onto. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 13 4pcs Washers (8x19x2.0t)(160) and 4pcs Socket Bolts (M8xp1.25x15mm)(131). d. Place the Non-Slip Pad (73) onto the Left Pedal (74). Repeat the above procedure on the right side. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 14 **Check whether the levelers are even on the floor (if the levelers are not even will produce noise), if not, review the LEVELING NOTE. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 15: Operational Instructions

    Hold the Front Stabilizer (2) up with two hands and tow the elliptical to the desired place carefully.  Make sure the floor is level while towing the elliptical. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 16 7. Console OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 17 TARGET HEART RATE and INTERVAL LEVEL. CLEAR RESET Press , all the date will return to 0 and the console will return to POWER ON status. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 18 TIME, DISTANCE, CALORIES, AGE, TARGET HEART RATE and INTERVAL LEVEL. DOWN (    ) b. During the workout, press to decrease the tension Level. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 19 10~99 years old; 1 year-old increment; the product is not recommended for children’s use. “B LUETOOTH AND ITNESS PPS” This console is Bluetooth built-in. Please ensure your mobile device is compatible with Bluetooth 4.0. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 20 The fitness apps – Kinomap or ZWIFT could be downloaded on App Store (iOS) or Google Play (Android). Please note these apps are supplied by 3 -party developers. We don’t take any responsibility for the availability, functionality, or contents of these fitness apps. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 21: Console Instructions

     Count Down: If you have set the target time (0 TO 99; 1 MINUTE INCREMENT), the console will count down from that selected target time down to 0:00. SET DISTANCE: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 22: Start Workout

     During workout, the allowed to adjust at any time by pressing UP (▲) or DOWN (▼) button to match your workout goal. 3” ENDING THE PROGRAM: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 23 RANDOM / INTERVAL / ROLLING Program Instruction: Press UP (▲) or DOWN (▼) button to select and then press ENTER button to enter RANDOM / INTERVAL / ROLLING PROGRAM. RANDOM INTERVAL OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 24  Shows the current energy (calories) burned.  Count Up: If the target calories were not selected, CALORIES will count up from 0 to 999 KCAL. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 25 “2” Boot Screen Display: a. After the console lights up with a short beep sound, the console will enter to POWER ON status. H.R.C. Program Instruction: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 26  Count Down: If you have set the target calories (10 TO 990 KCAL; 10 KCAL INCREMENT), the console will count down from that selected target calories down to 0. SET AGE: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 27 2. If you current pulse > (the value of the TARGET HEART RATE + 5 ), the console would decrease one resistance LEVEL automatically every 40 OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 28 Boot Screen Display: a. After the console lights up with a short beep sound, the console will enter to POWER ON status. VALLEY / MOUNTAIN Program Instruction: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 29  During workout, the is allowed to slight adjust at any time by pressing UP (▲) or DOWN (▼) button to match your workout goal. 3” ENDING THE PROGRAM: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 30 UP (▲) or DOWN (▼) button to select and then press ENTER button to enter DEFINE USER PROGRAM 1, or DEFINE USER PROGRAM 2, or DEFINE USER PROGRAM 3, or DEFINE USER PROGRAM 4. SET TIME: OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 31  Count Down: If you have set the target calories (10 TO 990 KCAL; 10 KCAL INCREMENT), the console will count down from that selected target calories down to 0. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 32: Set Level

    UP (▲) or DOWN (▼) button to match your workout goal. 3” ENDING THE PROGRAM: Press CLEAR RESET button to leave the program and enter POWER ON status. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 33: Conditioning Guidelines

    Adjust the intensity of your exercise until your heart rate is at the proper level. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 34: Warm-Up And Cool-Down

    A proper cool-down lowers your heart rate and allows blood to return to the heart. Your cool-down should include the stretches listed above and should be completed after each strength-training session. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 35: Maintenance

    Council or the retailer. 11. WARRANTY CONDITIONS Consult warranty conditions at www.salter.es. It is essential to indicate the serial number of the equipment for repairs under warranty. OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...

  • Page 36: Product Parts Drawing

    12. PRODUCT PARTS DRAWING OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
  • Page 37 PRODUCT PARTS DRAWING OWNER’S MANUAL V062023 ENGLISH M-9630/L ELLIPTICAL FENX This manual can be downloaded on www.salter.es...
