  • Page 1 MANUAL DEL USUARIO OWNER’S MANUAL MANUEL DE L’UTILISATEUR ELLIPTICAL OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 2 21. Make sure that adequate space is available for access to and passage around the equipment; keep at least a distance of 1 meter from any obstruction object while using the machine. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 3 “BEFORE YOU BEGIN” Thank you for choosing this SALTER equipment. We Too often, our busy lifestyles limit our time and take great pride in producing this quality product and opportunity to exercise. The Uright Bike provides a hope it will provide many hours of quality exercise to...
  • Page 4 Part No. and Description Q’TY HARDWARE KIT Lock Washer (M8) Washer (8x38x2.0t) 114 Nylon Nut (M10×p1.5) 139 Bolt (M8×p1.25×60mm) 142 Bolt (M10×p1.5×20mm) OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 5: Table Of Contents

    HARDWARE KIT Nylon Nut (M10xp1.5) Bolt (M5xp0.8x15mm) Bolt (M10xp1.5x85mm) Part No. and Description Q’TY HARDWARE KIT Washer (8x19x2.0t) Screw (M4×20mm) Bolt (M5xp0.8x15mm) Bolt (M8xp1.25x15mm) Bolt (M8×p1.25×16mm) OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 6 Cover Manillar superior Rotator Cuff-Pivoting Arm Rear Pivoting Arm Cover Accessory Tray Middle Pivoting Arm Upright Post Assembly Leveler Front and Rear Stabilizer Cover Main Frame OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 7: Bolt (M10Xp1.5X85Mm)

    Attach the Front Stabilizer (88) onto the position as the drawing 2 shown. Main Frame (1) and secure with 2pcs Washers (8x38x2.0t)(104), 2pcs Lock Washers (M8)(100) and 2pcs Bolts (M8Xp1.25x60mm)(139). OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 8 First fully secure with 2pcs Bolts (M10xp1.5x20mm)(142) at the front of the Upright Post (46). Then go back to fully tighten with 2pcs Nylon Nuts (M10xp1.5)(114). OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 9 Repeat the above same procedure on the left side. NOTE: Make sure the bolts and nuts are fully tightened before moving to the next step. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 10 4pcs Bolts (M5xp0.8x15mm)(127). c. Repeat the above same procedure on the left side. NOTE: Make sure the bolts are fully tightened before moving to the next step. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 11 Plug the Pulse Sensor Wire A (96) into the Pulse Sensor Wire B (97). Be careful not to pinch the wires. c. Place the Console (36) onto the Upright Post (46) and fully secure with 4pcs Bolts (M5xp0.8x15mm)(127). OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 12: Bolt (M8Xp1.25X15Mm)

    Attach the Left Pedal (74) onto the iron plate that is located in the middle of the Left Pedal Arm (70) and secure with 4pcs Washers (8x19x2.0t)(160) and 4pcs Bolts (M8xp1.25x15mm)(131). d. Place the Non-Slip Pad (73) onto the Left Pedal (74). OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 13 Repeat the above procedure (from c. to d.) to attach Right Pedal and Non-Slip Pad on the Right Pedal Arm. For the final step, make sure all the bolts and nuts are tighten securely before using. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 14 Hold the Front Stabilizer up with two hands and tow the item to the desired place carefully. Make sure the floor is level while towing the item OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 15 Console Kor Owner’s manual OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 16 TIME, DISTANCE, CALORIES, RPM, PULSE and WATTS. CLEAR RESET c. Continue pressing , all the date will return to 0 and the console will return to POWER ON status. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 17 WEIGHT, TIME, LEVEL and b. Press Target Heart Rate. DOWN () Level. c. During the workout, press to decrease the tension OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 18 15 to 250KGS / 30 to 400LBS; 1 KGS/LBS INCREMENT ; the product is not WEIGHT recommended for children’s use. • After pressing the ENTER button to confirm the desired value of WEIGHT. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 19 99:00; 1 MINUTE INCREMENT), the console will count down from that selected target time down to 0:00. NOTE: You can go back to re-set the value of WEIGHT by pressing CLEAR RESET button. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 20 90 seconds 10 ~ 19:59 minutes 120 seconds 20 ~ 29:59 minutes 180 seconds 30 ~ 39:59 minutes 240 seconds More than 40 minutes 300 seconds OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 21 RANDOM Program Instruction: (NOTE: The profile will be produced by randomly) Press UP (▲) or DOWN (▼) button to select and then press ENTER RANDOM PROGRAM. button to enter OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 22 • TENSION LEVEL During workout, the is allowed to adjust at any time by pressing UP (▲) or DOWN (▼) button to match your workout goal. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 23 After the console lights up with a short beep sound, the console will enter to POWER ON status and LED will display the scrolling message “CHOOSE PROGRAM OR QUICK START”. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 24 MINUTE INCREMENT), the console will count down from that selected target time down to 0:00. NOTE: You can go back to re-set the value of WEIGHT by pressing CLEAR RESET button. SET LEVEL: OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 25 10 ~ 19:59 minutes 120 seconds 20 ~ 29:59 minutes 180 seconds 30 ~ 39:59 minutes 240 seconds More than 40 minutes 300 seconds ENTER SUMMARY MODE : OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 26 “CHOOSE PROGRAM OR QUICK START”. H.R.C. Program Instruction: Press UP (▲) or DOWN (▼) button to select and then press ENTER H.R.C. PROGRAM. button to enter OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 27 250KGS / 30 ~ 400LBS; 1 KGS/LBS INCREMENT). 3. Press the ENTER button to confirm the value of WEIGHT. NOTE for WEIGHT: The product is not recommended for children’s use. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 28 • TENSION LEVEL During workout, the is allowed to adjust at any time by pressing UP (▲) or DOWN (▼) button to match your workout goal. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 29 TARGET HEART RATE ZONE in this example is 109 to 119. The program will monitor your pulse and adjust the resistance LEVEL automatically to keep your pulse within the HEART RATE ZONE (109 – 119) during workout OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 30: Program

    TIME  TOTAL DISTANCE  TOTAL CALORIES AVG. RPM  AVG. PULSE  AVG. WATTS. 3. Press CLEAR REST button third time to leave the program and enter POWER ON status. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 31: 1" Prior Information

    ~ 250KGS / 30 ~ 400LBS; 1 KGS/LBS INCREMENT). 3. Press the ENTER button to confirm the value of WEIGHT. NOTE for WEIGHT: The product is not recommended for children’s use. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 32 Press START button to start exercise. • TENSION LEVEL During workout, the allowed to adjust at any time by pressing UP (▲) or DOWN (▼) button to match your workout goal. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 33: Enter Summary Mode: Two Ways As Shown Below When Cool Down's

    POWER OFF: The console would automatically go to SLEEP mode after 1 minutes of inactivity. NOTE: the item will keep power on if you continue pedaling OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 34 MINUTE INCREMENT), the console will count down from that selected target time down to 0:00. NOTE: You can go back to re-set the value of WEIGHT by pressing CLEAR RESET button. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 35 90 seconds 10 ~ 19:59 minutes 120 seconds 20 ~ 29:59 minutes 180 seconds 30 ~ 39:59 minutes 240 seconds More than 40 minutes 300 seconds OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 36 “CHOOSE PROGRAM OR QUICK START”. MOUNTAIN Program Instruction: Press UP (▲) or DOWN (▼) button to select and then press ENTER button to enter MOUNTAIN PROGRAM. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 37 Press START button to start exercise. • TENSION LEVEL During workout, the allowed to adjust at any time by pressing UP (▲) or DOWN (▼) button to match your workout goal. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 38 POWER OFF: The console would automatically go to SLEEP mode after 1 minutes of inactivity. NOTE: the item will keep power on if you continue pedaling OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 39 MINUTE INCREMENT), the console will count down from that selected target time down to 0:00. NOTE: You can go back to re-set the value of WEIGHT by pressing CLEAR RESET button. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 40 90 seconds 10 ~ 19:59 minutes 120 seconds 20 ~ 29:59 minutes 180 seconds 30 ~ 39:59 minutes 240 seconds More than 40 minutes 300 seconds OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...

  • Page 41: Total Distance  Total Calories Avg. Rpm  Avg. Pulse  Avg. Watts

    TOTAL DISTANCE  TOTAL CALORIES AVG. RPM  AVG. PULSE  AVG. WATTS. 3. Press CLEAR REST button third time to leave the program and enter POWER ON status. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 42 Adjust the intensity of your exercise until your heart rate is at the proper level. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 43 A proper cool-down lowers your heart rate and allows blood to return to the heart. Your cool-down should include the stretches listed above and should be completed after each strength-training session. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
  • Page 44 WARRANTY CONDITIONS Consult warranty conditions at www.salter.es. It is essential to indicate the serial number of the equipment for repairs under warranty. OWNER’S MANUAL V.102021 ENGLISH M-9530 ELLIPTICAL KOR This manual can be downloaded on www.salter.es...
