49 NC
51 NC
53 GND
55 GND

2.2.2. PCIe Interface

DEBIX 4G board provides a PCIe interface (J54) with 19Pin/0.3mm FPC socket connector,
please refer to "FH26W-19S-0.3SHW(97)" on
to the PCIe interface of DEBIX motherboard.
The PCIe interface is defined as follows:
Table 4 Pin definition of PCIe
Pin Definition
1 GND
3 PCIE_RXN
5 PCIE_TXN
7 GND
9 PCIE_CLKN
www.debix.io
Polyhex Technology Company Limited
50
52
54
DEBIX website, which can be used to connect
Figure 4 PCIe interface
Pin
2
4
6
8
10
GND
4G_VDD3P3V
GND
Definition
PCIE_RXP
GND
PCIE_TXP
PCIE_CLKP
GND
11 / 25
