2.1. Overview
DEBIX 4G board provides 4G network capability for DEBIX motherboard. The data
specifications are as below:
Table 2 DEBIX 4G Board specification
I/O Interface
Mini PCIe
LED
Slot
PCIe
www.debix.io
Figure 2 DEBIX 4G Board
1 x Mini PCIe, support 4G module
1 x 4G Operation LED
1 x Micro SIM card slot (pop-up)
1 x PCIe, the connector is 19Pin 0.3mm Pitch FPC socket (Clamshell)
Polyhex Technology Company Limited
8 / 25
