DEBIX EMB-AS-05 User Manual page 10

The Mini PCIe interface is defined as follows:
Table 3 Pin definition of Mini PCIe
Pin Definition
1 NC
3 NC
5 NC
7 NC
9 GND
11 NC
13 NC
15 GND
17 NC
19 NC
21 GND
23 NC
25 NC
27 GND
29 GND
31 NC
33 NC
35 GND
37 GND
39 4G_VDD3P3V
41 4G_VDD3P3V
43 GND
45 NC
47 NC
www.debix.io
Polyhex Technology Company Limited
Pin Definition
2 4G_VDD3P3V
4 GND
6 NC
8 USIM_POWER
10 USIM_DATA
12 USIM_CLK
14 USIM_RESET
16 USIM_VPP
18 GND
20 4G-DISABLE
22 4G-RESET
24 4G_VDD3P3V
26 GND
28 NC
30 NC
32 NC
34 GND
36 4G_USB_DM
38 4G_USB_DP
40 GND
42 4G_VDD3P3V
44 NC
46 NC
48 NC
10 / 25
