- Page 1 USB 2.0 Extender Over Ethernet Model 202159 Supports up to 164ft via CAT 5e/6 cable User Manual Download the user manual at: www.cablematters.com/dl/202159 support@cablematters.com...
-
Page 2: Table Of Contents
USB 2.0 Extender over Ethernet Table of Contents 1. INTRODUCTION ..................1 1.1 Introduction 1.2 Copyright and Trademarks 1.3 FCC Compliance Statement 2. PRODUCT OVERVIEW 2.1 Package Contents 2.2 Product Description ................2 2.3 Product Features 3. CONNECTION AND OPERATION .............. 3 3.1 Installation Checklist 3.2 Transmitter Panel Connections 3.3 Receiver Panel Connections .............. -
Page 3: Introduction
Contact support@cablematters.com for questions or product support. 1.2 Copyright and Trademarks Cable Matters is a registered trademark or trademark of Cable Matters Inc. All rights reserved. All other trademarks are the property of their respective owners. Dolby, Dolby Audio and the double-D symbol are trademarks of Dolby Laboratories. -
Page 4: Product Description
USB 2.0 Extender over Ethernet 2.2 Product Description The Cable Matters USB 2.0 Extender extends USB signals up to 50 meters (164ft) through Cat 5e/6 cable. On Transmitter side, utilize the USB-B port to connect to a computer's USB-A port. -
Page 5: Connection And Operation
USB 2.0 Extender over Ethernet 3. CONNECTION AND OPERATION 3.1 Installation Checklist Installation with a surge protector is recommended to protect the equipment Check for nearby AC outlets for the power adapters Directly connect to a Cat 5e/6 cable, do not use with an active hub, network switch or router ... -
Page 6: Receiver Panel Connections
USB 2.0 Extender over Ethernet 3.3 Receiver Panel Connections 1) USB2.0 Port: Connect various USB devices to achieve a high transfer rate of 480Mbps. 2) Power LED: The Power LED indicator, marked by a green light, illuminates when a power adapter is successfully connected to the Receiver. 3) DC 5V: Connect the 5V/1A DC power adapter to this port. -
Page 7: Troubleshooting Notes
USB 2.0 Extender over Ethernet 3.5 Troubleshooting Notes Check that both the Transmitter and Receiver have power. The green LED on both the • Transmitter and Receiver should be lit. Check that all cables are connected well to the correct ports •... -
Page 8: Technical Specifications
USB 2.0 Extender over Ethernet 4. TECHNICAL SPECIFICATIONS Model 202159 Extender Ports (Transmitter and Receiver) USB Input 1x USB-B Female USB Output 2x USB-A Female Network Ports 2x RJ45 Female Power (Receiver) 1x 5V DC2.1 Female Technical USB Compatibility USB2.0 and USB3.0 devices... -
Page 9: Warranty And Support
USB 2.0 Extender over Ethernet 5. WARRANTY AND SUPPORT 5.1 Customer Support and Contact Information Cable Matters offers lifetime technical support as an integral part of our commitment to provide industry leading solutions. Email us with any questions at support@cablematters.com. - Page 10 USB 2.0 Extender over Ethernet THIS PAGE LEFT INENTIONALLY BLANK www.cablematters.com...
