Eden 94156EDAMZ Quick Start Manual

6-PATTERN ROTARY GEAR DRIVE SPRINKLER
Tripod
length
63.7"
(162cm)
Step 1
Place the tripod in the area where you
want to water. Open the latches to
release the legs. Push down on the
tripod legs until the legs are well seated
on the ground.
43.7"
(111cm)
18.7"
(47.5cm)
WITH TELESCOPING TRIPOD
Range tab - adjust range and prevent water waste
6 spray patterns to meet all your watering needs
- at, fan, large, jet, full and mini
Connects to any Eden sprinkler base with "H"
shape or tripod base
Spray Angle - adjust the tabs to change the spray
angle from 5° to 360°
Added lter to prevent water sediment
Step 2
Attach the Extension Tube to the tripod, then
connect the sprinkler head to the top of the
Tripod or Extension Tube (do not overtighen).
Step 3
Using the Quick Connect with Shut O
tools without having to return to the faucet – saving time and water. Attach the lockable Quick
Connect to the end of the hose, then snap the hose to the tripod to begin using.
Note: If you are not using the
Quick Connect System, connect
the sprinkler directly to the hose.
Filter prevents sediments
and dirt from getting into
sprinkler
Valve allows you to easily shut o
Quick Connect Starter Set
with Shut O Valve ts
standard garden hoses and
watering tools
94156EDAMZ
the water and swap
