- Page 1 Naga 80 Soundbar User Manual H O M E A U D I O • C A M B R I D G E...
-
Page 2: Table Of Contents
Contents What’s In the Box?......................Basic Information…………………………..…………………………………………........ Controls and Functions……………………………………………………………………......Connecting to the Power Outlet…………………………………………………………………………… Display Icons……………………………………………………………………………………………………….. Audio Settings……………………………………………………………………………………………………… Instructions Guide………………………………………………………………………………………………… USB Input………………………………………………………………………......ARC Input……………………………………………………………………...…………………….. Optical Input………………………………………………………………………………………… AUX Input…………………………………………………..........Bluetooth…………………………………………………………………........ Troubleshooting………………………………………………………………………………......Specification…………………………………………………………………………………......Warranty………………………………………………………………………………………………………………. Support……………………………………………………………………………………………………………….. Regulatory Information…………………………………………………………………………………………. Safety Information……………………………………………………………………………....... EU Declaration of Conformity…………………………………………………………………………….. -
Page 3: What's In The Box
Box Contents What’s in the Box? Majority NAGA 80 Soundbar Wall mount bracket x 2 Remote Control 2 x AAA batteries ARC Cable Welcome Guide 3.5mm to RCA stereo audio cable User Manual Power Adaptor Note: Remote control (B) requires 2 x AAA batteries (included). lt is recommended to... -
Page 4: Basic Information
Basic Information Automatic Power Off Function The Majority NAGA 80 will automatically go into Standby Mode after 180 minutes of no audio signal/sound received from the device that is connected with, or if the TV/ device is switched off. Installing the Soundbar to the Wall This part of instruction shows those steps on preparing the installation of the Soundbar before hanging it on the wall. -
Page 5: Controls And Functions
Controls & Functions Majority Naga 80 Control Functions Front, Top & Rear View Left & Right Speaker Drivers Adjust volume up or down. 4 digits LED display screen & Subwoofer Speaker Driver Remote Sensor 3.5mm AUX Input port Power ON/OFF... - Page 6 Controls & Functions Remote Control Buttons Power On/Off. INPUT: Press to switch between modes. Play/Pause: In Bluetooth/USB mode, press to pause/play media. Back: Use in Bluetooth and USB modes to go back a track. Volume – Adjust volume. Default: To return factory settings. Bass +/-: To adjust during MUSIC, MOVIE or DIALOG mode.
-
Page 7: Connecting To The Power Outlet
Connecting to The Power Outlet Connecting to the Mains Socket Ensure that the power supply voltage is within the range of 100V~240V. Any other voltage may cause damage to the unit. Unwind the mains cable to its full length. Connect the mains plug to a mains socket. Ensure that the mains plug is fully inserted into the mains socket. -
Page 8: Display Icons
Display Icons Display Icons Remote Input Control Display Button Connecting the soundbar with the Optical Cable (not OPTICAL OPTICAL included), e.g. to the optical port of the TV/device. Connecting the soundbar with HDMI(ARC) Cable, to the HDMI(ARC) port of the TV. Pairing the soundbar via Bluetooth with a TV, phone, or other... -
Page 9: Audio Settings
Audio Settings Audio Settings Bass/Treble Options dB(decibels) Mode refers to sound level. Manually change BASS and TREBLE MUSIC settings (between 0 dB and +8 dB). Manually change bass and treble setting DIALOG (between 0 dB and +8 dB). Manually change bass and treble setting MOVIE (between 0 dB and +4 dB). -
Page 10: Usb Input
USB Input Please note that the instructions within this user manual will refer to the button number on the soundbar (Ref ‘number’), or buttons on remote control e.g. (Rem. ’number’), in accordance with the diagrams from pages 5 and 6. Using the USB Playback Port Plug in a USB stick to the USB jack port (Ref.9) on the soundbar. -
Page 11: Arc Input
ARC Input Using the ARC Input Before connecting, switch off both the soundbar and TV. Plug in the ARC cable (included) to the ARC jack port on the rear panel of the Soundbar (Ref.8). Plug the other end of the cable into the TV’s ARC output port. Ensure the TV port that you are using is marked as ARC. -
Page 12: Optical Input
Using the native controls on your connected device, make sure the audio settings are on and set to PCM or Optical Audio. Audio from the connected audio source will now be heard through the NAGA 80. Optical Cable Rear view of unit... -
Page 13: Aux Input
(Rem.14) repeatedly until AUX In Mode is selected. The LED screen must display ‘ ‘. Turn on the soundbar and TV or external devices etc. accordingly and audio will now be heard through the Majority NAGA 80. 3.5mm to RCS audio cable... -
Page 14: Bluetooth
Switch your device’s Bluetooth connectivity on and start searching for the soundbar. Select the 'NAGA 80' from your device’s list when prompted to pair with the soundbar. If a password is required, enter '0000'. If you encounter issues at this stage, please refer to the user manual of your device for instructions on pairing and connecting with other Bluetooth devices. -
Page 15: Troubleshooting
Troubleshooting Observation Potential Cause/Solution Check that the power is switched on at the wall socket. No power/function Check that the power adapter is properly connected to the power outlet. Check whether the unit is set to MUTE. Check that cables are properly installed. If cables are properly installed, please try No sound connecting to your TV using an alternative... -
Page 16: Specification
'Register Your Product'. You will also be given the chance to extend your warranty for an additional 24 months, free of charge. Support If you require further assistance with your new Majority NAGA 80, please contact our support team on the Majority website: www.majority.co.uk/support. -
Page 17: Regulatory Information
Regulatory Information NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 18: Safety Information
Read these instructions. ADDITIONAL WARNINGS Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping, available for download at www.majority.co.uk. splashing or objects filled with water. Heed all warnings. Follow all instructions. The main plug is used to disconnect the device. In Do no clean the apparatus near or with water. -
Page 19: Eu Declaration Of Conformity
EU Declaration of Conformity I hereby declare that the product: Product Name: NAGA 80 Soundbar Model: 1000002969 Brand Name: Majority Satisfies all the technical regulations applicable to the product within the scope of Council Directives 2014/35/EU and 2014/30/EU, 2009/125/EC, 2012/19/EU, 2014/53/EU, 2011/65/EU, 1907/2006.
