Summary of Contents for MAJORITY TETON
- Page 1 T E T O N U S E R M A N U A L H O M E A U D I O • C A M B R I D G E...
-
Page 2: Table Of Contents
Connecting to the Power Outlet ����������������������������������������������������������������������������������� 13 Bluetooth ��������������������������������������������������������������������������������������������������������������������� 14 Troubleshooting ���������������������������������������������������������������������������������������������������������� 15 Spec, Support & Warranty �������������������������������������������������������������������������������������������� 16 Regulatory Information ������������������������������������������������������������������������������������������������ 17 Safety Information ������������������������������������������������������������������������������������������������������� 18 YEAR Register your product online for a FREE 3 year WARRANTY extended warranty at: www�majority�co�uk... -
Page 3: Controls & Functions
CONTROLS & FUNCTIONS FRONT, SIDE, AND REAR VIEW Speaker drivers LED Indicator Light Remote control sensor On/Off Change mode (BT, OPTICAL, AUX, RCA, USB, ARC). Adjust volume AUX in socket Bluetooth pair button USB socket RCA socket ARC/HDMI in socket OPTICAL in socket DC 18V socket... - Page 4 CONTROLS & FUNCTIONS REMOTE CONTROL Power on/off Bass increase/decrease Volume + Back: Use in Bluetooth and USB modes to go back a track. Play/Pause: In Bluetooth/USB mode, press to pause/play media. Volume - Treble increase/decrease Media modes: Select Music, Dia- logue or Movie EQ mode Flat: Press to reset EQ settings to default...
-
Page 5: Box Contents
BOX CONTENTS WHAT’S IN THE BOX? Majority Teton Soundbar RCA Stereo Audio Cable Remote Control HDMI Cable Instructions Guide Optical Cable 3.5mm to 3.5mm Audio cable Power Adapter Note: Remote control (B) requires 2 x AAA batteries (not included). It is recommended... -
Page 6: Additional Info
TV is switched off, or if there is any audio signal in. Wall mounting The Majority Teton can be mounted to a wall using the appropriate fittings for your wall type by using the wall mounting brackets positioned at the rear of the unit. As these differ between wall types the fittings are not included. -
Page 7: Mode Indicator Lights & Audio Settings
MODE INDICATOR LIGHTS & AUDIO SETTINGS MODE INDICATOR LIGHTS State Indicator Lights Power off AUX mode Green USB mode Purple RCA mode White ARC mode Light blue Optical mode Yellow Bluetooth ready Flashing blue Bluetooth connected Blue AUDIO SETTINGS Bass/Treble Options Mode Db (decibels) refers to sound level. -
Page 8: Usb Input
USB INPUT USING THE USB INPUT Connect your USB device to the USB jack (Ref.9) on the soundbar. Press the ‘INPUT’ button (Ref.24) on the remote, and the LED indicator will be Purple. Play music files from the USB device through the soundbar. USB Device Rear panel of soundbar... -
Page 9: Rca Input
RCA INPUT USING THE RCA INPUT Use the RCA Stereo Audio Cable to connect the TV’s stereo RCA(L/R) audio output socket to the RCA(L/R) Sockets of the unit (Ref.10). Then press the INPUT button on the remote control (Ref.24) or press the INPUT button on the soundbar (Ref.5) to choose the AUX function. -
Page 10: Arc Input
ARC INPUT USING THE ARC (HDMI) INPUT Connect the HDMI cable (included) to the HDMI ARC connector on the back of the unit to the HDMI (ARC) connector on the TV. NOTE: In the HDMI ARC mode, if your speakers have no audio output and the indicator light is flashing quickly, use your source device (such as a TV, CD player, or cable/ satellite receiver).The audio output mode is set to PCM, or turn off the sound source output. -
Page 11: Optical Input
OPTICAL INPUT USING THE OPTICAL INPUT You will need: An audio source with an Optical Audio Output and a Digital Optical Audio cable (included). Connect the Digital Optical Audio cable to the optical output on the audio source and to the Optical Input on the soundbar (Ref.12). Press the POWER button on the side panel (Ref.4) or on the remote control (Ref.14) to switch on the unit. -
Page 12: Aux/Line In Input
AUX/LINE IN INPUT USING THE MP3 LINK CONNECTION (AUX IN) Plug one end of a 3.5mm audio input cable (included) into the Line in (Ref.7) on the unit. Before use, disconnect any cables connected to the Stereo RCA Inputs. Plug the other end of the cable into the audio output/ headphone output on an MP3 player or other audio source. -
Page 13: Connecting To The Power Outlet
CONNECTING TO THE POWER OUTLET CONNECTING TO THE MAINS SUPPLY Ensure that the power supply voltage is within the range of 100V~240V. Any other voltage may cause damage to the unit. Unwind the mains cable to its full length. Connect the mains plug to a mains socket. Ensure that the mains plug is fully inserted into the mains socket. -
Page 14: Bluetooth
(Ref.5) repeatedly until Bluetooth mode is selected (indicated by a flashing blue light). From your Bluetooth device, select the “Majority Teton” when prompted to choose a Bluetooth device. If a password is required, enter “0000”. If you encounter issues at this stage, please refer to the user manual for your Bluetooth device for instructions on pairing and connecting Bluetooth devices. -
Page 15: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING If you encounter an issue with your soundbar, please refer to the following checklist. Observation Potential Cause/Solution Check that the power is switched on at the wall. No power/function Check that the power adaptor is properly connected to the power outlet. Check whether the unit is set to MUTE. -
Page 16: Spec, Support & Warranty
81.2 x 9.6 x 10.2cm Net Weight 1.5kg SUPPORT If you require further assistance with your new soundbar, please contact our support team on the Majority website: www�majority�co�uk/support WARRANTY All products come with a standard 12 month warranty. All items must be registered www�majority�co�uk for the warranty to be valid. -
Page 17: Regulatory Information
REGULATORY INFORMATION NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 18: Safety Information
ADDITIONAL WARNINGS 2. Keep these instructions. Instructions are also availa- The apparatus shall not be exposed to dripping or splash- ble for download at www.majority.co.uk ing and no objects filled with liquid, such as vases, shall 3. Heed all Warnings be places on the apparatus. - Page 20 H O M E A U D I O • C A M B R I D G E WWW.MAJORITY.CO.UK...
