DESCRIPTION OF THE DEVICE

MENU
ENTER
9 10 11
Note: When connected correctly, the power and DMX sockets are protected from spraying water according
to IP65. When not in use, make absolutely sure to close the sockets with the rubber sealing caps.
UP
DOWN
12 13 14 15
1
(1) Lens/LED
2
(2) Infrared sensor
3
(3) Thread for the frost filter
4
(4) Fixation screw
5
6
(5) Mounting hole for the clamp
(6) Floor stand/mounting bracket
(7) Safety eyelet
7
(8) Control Board with operating buttons
8
(9) Power button
(10) DMX input
(11) Power output
(12) Kensington security slot
(13) Antenna
(14) Power input
(15) DMX output
(16) Pressure compensation membrane
