DESCRIPTION OF THE DEVICE

(1) Fixation screw
(2) Diffuser disc mounting screws
(3) Infrared sensor for the remote control
(4) 10 W RGBWA/UV LEDs
(5) Mounting and stand bracket
(6) DMX input
(7) LCD display and operating buttons
1 2 3
7
6
11
9 10
25/40
4 2 1
5
8
12 13
(8) DMX output
(9) Power on/off
(10) Power input
(11) Safety eyelet
(12) Power output
(13) Pressure compensation plug
