DMX Protocol

3-channel mode
Channel Value
1 0-255
2 0-255
3 0-255
4-channel mode
Channel Value
1 0-255
2 0-255
3 0-255
4 0-255
6-channel mode
Channel Value
1 0-255
2 0-255
3 0-255
4 0-255
5 0-255
6 0-14
15-255
8-channel mode
Channel Value
1 0-255
2 0-255
3 0-255
4 0-255
5 0-255
0-14
6
15-255
0-31
32-63
64-95
7
96-127
128-159
160-191
192-223
224-255
8 0-255
Feature
Red, Green and Blue color mixing
White, 0 - 100 % increasing
Dimmer, 0 - 100 % increasing
Feature
Red, 0 - 100 % increasing
Green, 0 - 100 % increasing
Blue, 0 - 100 % increasing
White, 0 - 100 % increasing
Feature
Red, 0 - 100 % increasing
Green, 0 - 100 % increasing
Blue, 0 - 100 % increasing
White, 0 - 100 % increasing
Dimmer, dimmer intensity from 0 to 100 %
Strobe
LEDs on
Strobe effect with increasing speed
Feature
Dimmer, dimmer intensity from 0 to 100 %
Red, 0 - 100 % increasing
Green, 0 - 100 % increasing
Blue, 0 - 100 % increasing
White, 0 - 100 % increasing
LEDs on
Strobe effect with increasing speed
Fading in/out
Neutral
Fade in (0 % - 100 %) (speed and effect depending on the control
channels 1 - 5)
Fade out (100 % - 0 %) (speed and effect depending on the control
channels 1 - 5)
Fade out and fade in (100 % - 0 % - 100 %) (speed and effect depending
on the control channels 1 - 5)
Program "Fading"
Program "Fade out - fade in"
Program "Switching"
No function
Speed Fading in/out and programs channel 7
increasing speed
