Clean Water Made Easy
www.cleanwaterstore.com
5900S Neutralizer
Operation & Maintenance
Manual
Thank you for purchasing a Clean Water System! With
proper installation and a little routine maintenance your
system will be providing neutral pH water for many years.
Please review this start‐up guide entirely before beginning to
install your system, and follow the steps outlined for best
results.
CALCITE MEDIA CONTAINS DUST. USE PAPER MASK AND
VENTILATE TO AVOID BREATHING DUST (Use a spray bottle to
wet the media down).
Helpful Videos:
https://www.youtube.com/channel/UC415QpvlRz-
YAntxlMieI2w/videos
Questions?
Call us toll-free: 1-888-600-5426 or 1-831-462-8500
Email us:
support@cleanwaterstore.com
See more information on our website:
www.cleanwaterstore.com/resources
Advertisement
Table of Contents
Related Manuals for Clean Water Systems 5900S
Summary of Contents for Clean Water Systems 5900S
- Page 1 Clean Water Made Easy www.cleanwaterstore.com 5900S Neutralizer Operation & Maintenance Manual Thank you for purchasing a Clean Water System! With proper installation and a little routine maintenance your system will be providing neutral pH water for many years. Please review this start‐up guide entirely before beginning to install your system, and follow the steps outlined for best results.
-
Page 2: Table Of Contents
Neutralizer Filter 2.0 cubic foot size ......................3 Neutralizer Filter 2.5 cubic foot size ......................3 How Your neutralizer Works: ........................4 Fig. 1: Typical Neutralizer 5900S piping installation: ................... 5 Pre-Installation: ............................. 6 Best Practices for Piping & Drain Installation: ....................6 Fig 3. -
Page 3: Font Used In Paper Guide Is Small, To Save Paper. Pdf Version Available On Our Website
Font used in paper guide is small, to save paper. PDF version available on our website. Packing List: All systems include: 5900S control valve, bypass assembly with 1” connector yoke, power supply and top screen. Neutralizer Filter 1.0 cubic foot size 9”... -
Page 4: How Your Neutralizer Works
5900S Neutralizer Operation & Maintenance Manual How Your neutralizer Works: See Fig 1 on the right. In your Neutralizer, the water enters the top of the tank (red arrows) and flows down through the media and up the distributor tube (blue arrows). The downflow type Neutralizer raises the pH of your water and can be backwashed, which cleans and re-classifies the Calcite, preventing channeling. - Page 5 5900S Neutralizer Operation & Maintenance Manual Fig. 1: Typical Neutralizer 5900S piping installation: Page 5 www.cleanwaterstore.com Rev 110117...
-
Page 6: Pre-Installation
1. See typical installation. The Neutralizer is installed after the pressure tank. 2. Make sure to connect the IN pipe to the 5900S inlet and the OUT pipe to the outlet (see Fig 2). As you face the 5900S control from the front, the water enters on the right and exits on the left. -
Page 7: Installation Of Your System Into Copper Or Metal Piping Systems
5900S Neutralizer Operation & Maintenance Manual Installation of Your System into Copper or Metal Piping Systems: If your new filter system is to be installed in a metal (conductive) plumbing system, i.e. copper or galvanized steel pipe, the plastic components of the system will interrupt the electrical continuity of the plumbing system. -
Page 8: Fig 3. 5900S Bypass/Service Mode Knob Positions
5900S Neutralizer Operation & Maintenance Manual Fig 3. 5900S Bypass/Service Mode Knob Positions: Outlet, treated water to house Inlet, from water source ON THE LEFT: FILTER IS BYPASSED! ON THE RIGHT, FILTER IS IN SERVICE! Assembly and Installation Instructions: Page 8 www.cleanwaterstore.com... - Page 9 5. Fill tank up with water, just below the threads, add an ounce of bleach to sanitize. 6. Attach plastic top screen to the under-side of the 5900S control valve. It may twist on clockwise or counter-clockwise. Page 9 www.cleanwaterstore.com...
- Page 10 Add a small amount of silicone grease to the large O-ring on the bottom of the control valve and screw on 5900S control valve carefully. Do not use pipe-joint compound, vegetable oil, Teflon tape, or Vaseline or other petroleum greases to lubricate tank threads.
-
Page 11: Programming Your Valve
It is OK to run the drain line up and over the 5900S Carbon Filter up to 4 feet above the top of the tank. If the drain line will be more than 20 feet, use larger diameter tubing such as ¾”... -
Page 12: Master Programming Mode
5900S Neutralizer Operation & Maintenance Manual 1. To enter main menu press the Menu/Enter button (Time of day will flash) 2. To set time of day press the Set/Change button (First digit will begin to flash) - To change digit value press the Set/Change button... -
Page 13: Programming With Flow Sensor Option
5900S Neutralizer Operation & Maintenance Manual Set each step to the values below, appropriate for a neutralizer filter: 10 minutes. This is the Backwash cycle. [ 1 - 10 ] 5 minutes. This is the Rest cycle. [ 2 - 5 ] 6 minutes. -
Page 14: Initial Backwash
5900S Neutralizer Operation & Maintenance Manual Initial Backwash: 1 If days remaining is not already at 1 press and hold the Set/Change button. Now, press and hold the set change button again, until the valve begins the backwash cycle and the display reads 1 –... -
Page 15: Maintaining Your Neutralizer
5900S Neutralizer Operation & Maintenance Manual Maintaining Your Neutralizer 1. Check the pH before and after the neutralizer. You want to have a pH of at least 7.0 after the neutralizer filter. 2. If the pH drops below 7, check the depth of the Calcite media by shining a bright light through the tank. - Page 16 5900S Neutralizer Operation & Maintenance Manual For most residential well applications, a 90% Calcite and 10% Corosex is best. However, in some cases an 80%/20% mix or even a 70%/30% is used. It is always better to start with a 90%/10% mix at first as this solves most of low pH problems in the range of 4.5 to 5.9.
-
Page 17: Normal Operation
To confirm that the battery is working, press either button and the display will turn on for five (5) seconds. • If power failure occurs while system is regenerating, the 5900S will motor to a shut off position to prevent constant flow to drain. Depending upon system pressure and other factors, it is possible to observe a reduced flow to drain during this step. -
Page 18: Troubleshooting The 5900S Neutralizer Filter
Neutralizer filter. You can verify the backwash flow rate by running the drain line into a bucket and timing it when the 5900S is in Cycle 1 or backwash. A 1.0 or 1.5 cubic foot system should have 5 gallons per minute and a 2.5 cubic foot system should have 7 gallons per minute of backwash. -
Page 19: White Spots On Fixtures And Glasses
5900S Neutralizer Operation & Maintenance Manual time, and after several weeks, if the pH is still coming out less than 7 and the test reagent is yellowish in color, you may need to add some Corosex to the neutralizer tank to raise the pH. -
Page 20: Drain Line Flow Control Housing
5900S Neutralizer Operation & Maintenance Manual Drain Line Flow Control: This has already been installed, you need only attach your tubing and secure it with a ring clamp. If it leaks where the clip inserts, remove the clip and re-insert the fitting. You must do this with the cover off and you must be looking at where you are inserting it. -
Page 21: Powerhead Assembly
5900S Neutralizer Operation & Maintenance Manual Powerhead Assembly: Description Part Number Item Code 0 Timered Power Head Assy. 21001X100 V5037310 0 Metered Power Head Assy. 21003X100 V5037320 1 Filter Circuit Board Assy. 21002X102 V5037250 2 Encoder 20001X124 V5036550 3 Front Plate... -
Page 22: Valve Body Assembly
5900S Neutralizer Operation & Maintenance Manual Valve Body Assembly: Description Part# Item Code 1 Piston Assembly 20001X231 V5036380 2 10-24 X 13/16” Screw 20001X226 V3003030 3 Seal and Spacer Kit 20561X253 V5036410 4 End Spacer 20001X234 V5037300 5 Flow Control Button 5.0 GPM 20251X272 V5035780 5 Flow Control Button 7.0 GPM... -
Page 23: Water Filters/ Softeners/ Conditioners Limited Warranty
5900S Neutralizer Operation & Maintenance Manual Water Filters/ Softeners/ Conditioners Limited Warranty: We warrant this water filter/ softener/ conditioner, when installed according to factory recommendations, to be free from defects in materials and workmanship as follows: ‐‐‐‐‐‐‐‐‐‐Limited Warranty‐‐‐‐‐‐‐‐‐‐ This water conditioner unit is comprised of the finest industry components available. Each individual component used in the assembly of our equipment is covered by the original equipment manufacturer’s warranty.
