  • Page 1 Media Dot INSTALLATION GUIDE V1.0...
  • Page 2: Table Of Contents

    Content Safety And Operation Introduction Installation 4.    System Configuration  Care and Maintenance 6.    Technical Specification  7.    Troubleshooting  Warranty Statement For your own safety and that of the product, please read this installation guide carefully before  beginning setup and installation. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 2 of 21...
  • Page 3: Safety And Operation

    If the product has been subjected to drastic temperature variances, for example, following  transportation, do not connect the fixture until it has reached room temperature, as moisture  condensation may cause electric shock and product damages. When installing the products and system power supplies, please ensure they will not be exposed  to moisture and extreme heat (and direct sunlight for outdoor products). Besides, keep a clean  operating environment for the fixtures and system power supplies. Please study this Installation Guide thoroughly and check the latest Technical Specification Sheets  available from the Traxon website www.traxon-ecue.com before setup. Any non-compliance of the Installation Guide will void the Traxon warranty. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 3 of 21...
  • Page 4: Introduction

    Diffused View and Direct View — DMX512 — Daisy Chain System with quick lock connectors — Manual-Addressing with TX Smart Addresser (Addressing IC: SM19522SK) — IP67, Suitable for Coastal Environment, IK06 and 3G Vibration Resistant Dimensions FIG.1:  Media Dot Go S 13.3mm [0.5"] 13.3mm [0.5"] 3.2mm [0.1"] R11.8mm [0.5"] 10.3mm [0.4"] 13.5mm [0.5"] 22.3mm [0.9"] 25.4mm [1"] 25.4mm [1"] ∅23.3mm [0.9"] R11.8mm [0.5"]...
  • Page 5 FIG.2:  Media Dot Go M 13.3mm [0.5"] 13.3mm [0.5"] 3.2mm [0.12"] R16mm [0.6"] 16.5mm [0.7"] 25.7mm [1"] 29.5mm [1.2"] 25.7mm [1"] 1.5mm [0.1"] 14.5mm [0.6"] 43.7mm [1.7"] ∅32.1mm [1.3"] R16mm [0.6"] Direct View Diffused View 43.7mm [1.7"] 43.7mm [1.7"] NOTE: Please see CAD files for additional dimensional data.
  • Page 6 FIG.4:  Media Dot Go Accessories Starter Cable 1m / 3.3’ (DA23100131055) Starter Cable 5m / 16.4’ (DA23100131155) 40.8mm /1.6” 1m, 5m / 3.3’, 16.4’ Ø6.8mm / 0.3” Connector Pin Assignment Input Output End Cap (DA23100131255) Wire# Description Color 36.9mm / 1.5”...
  • Page 7 Media Dot 300mm / 11.8" Differs by region 300mm / 11.8" Differs by region 300mm / 11.8" Differs by region Please consult your local Traxon office or authorized agent for necessary aid. NOTE: Please see CAD files for additional dimensional data. Packing Contents FIG.6:  Media Dot Go Packing Contents Direct View Diffused View www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES.
  • Page 8: Installation

    Points To Consider Plan your installation before mounting the Media Dot Go. The following should be considered for a  successful installation. — Appropriate cable lengths (cable gauges described in system diagram). Please consult your local  Traxon office or authorized agent for necessary aid. — The number of the Media Dot Go and an appropriate power supply. — Mounting distances should be considered. — Proper surge protection. — Weather conditions and ambient temperature of installation site. Starter Cable 1m / 3.3’ (DA23100131055) Starter Cable 5m / 16.4’...
  • Page 9 Mount the Media Dot Go on-site. If the installation is to be left uncompleted overnight, place all  non-connected power supply and the Media Dot Go in an indoor environment. All units must be connected or utilize end caps to protect from water ingress. Ensure all the Interconnection Cables, Media Dot Go and power supply are initially stored in a dry area to guarantee the complete sealing of the system from water before installation. 3.2.2 Handling The Media Dot Go String Please take care when transporting or preparing the Media Dot Go string. Carry the Media Dot Go ...
  • Page 10 300mm / 11.8" 300mm / 11.8" The flat Media Dot Go Cable must NOT be bent / twisted below 20mm (0.79”) from edge of Media Dot  Go housing (Non-Bendable / Non-Twistable Length).  Twisting the flat cable is NOT recommended. If twisting is necessary for installation, please adhere  to the above Non-Twistable Length and ensure the mounting pitch is greater than or equal to 75% of  the normal Media Dot Go to Media Dot Go pitch. The middle part of the cable must be secured to the mounting fixture with a cable tie (see “3.3 On-Site Installation” on page 12 ). Ensure no damage is  generated on the cable.  FIG.10:  Minimum Clearance Minimum clearance from dot 20mm/0.79”...
  • Page 11 Always keep the Waterproof End Cap on the chain end or keep them safe in a container for reuse. Connect Media Dot Go manner outlined in the System Diagram to form large installations. Perform functional check on all Media Dot Go and inspect cables for any damage. Check for any  abnormalities with the signal. Report any functional defect found to your nearest local Traxon office. DO NOT attempt to install the Media Dot Go with functional defects on-site. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0...
  • Page 12 Failure to keep Media Dot o within the operating temperature range of -30°C  to +50°C (-22°F to +122°F) and storage temperature range of -40°C to +70°C  (-40°F to +158°F) will void the product’s warranty. 3.3.1 Mounting Media Dot Go Media Dot Go must be mounted without any stress induced at the boundary area of the cable and Media Dot Go. Media Dot Go MUST be mounted to the installation surface via the mounting holes, either by  3mm or 1/8” screws or cable tie. FIG.12:  Mounting the Media Dot Go Direct View 3mm or 1/8"...
  • Page 13 If you do not hear the “click”, pull connector manually to lock the connectors and ensure that they are properly mated to protect from water ingress. Please note the direction of connection. Do not connect in reverse. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 13 of 21...
  • Page 14: System Configuration

    System Configuration System Diagram FIG.16:  System Diagram of Media Dot Go S www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 14 of 21...
  • Page 15 FIG.17:  System Diagram of Media Dot Go M www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 15 of 21...
  • Page 16 FIG.18:  System Diagram of Media Dot Go L www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 16 of 21...
  • Page 17: Care And Maintenance

    — Do not use product(s) in extreme heat environment. Ensure there is sufficient airflow and use cool  air circulation if required. — Do not drop, knock, or shake product(s). Rough handling can damage the electronics and void the  warranty. — Do not use harsh chemicals, cleaning solvents, or strong detergents to clean products. Wipe with a  damp cloth on housings and a dry cloth on electronics to remove dirt or dust. — Do not attempt to service or repair the product(s) unless done by an authorized service personnel.  Contact your local Traxon office or distributor for details. — If the product is not working as specified, please contact your nearest authorized service center  or Traxon Technologies office for assistance.  — The light source of this luminaire is not replaceable; when the light source reaches its end of life the  whole luminaire shall be replaced. * Options vary by region www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 17 of 21...
  • Page 18: Technical Specification

    12 RGB + 3 White 12 RGB  6 2700K + 6 6500K 6500K Beam Angle: 110° 150° Power Input: 24V DC Power Consumption (typ).: Weight: 32.5g Operating Temperature: -30°C to +50°C (-22°F to +122°F) Storage Temperature: -40°C to +70°C (-40°F to +158°F) Addressing Options Manual-Addressing with TX Smart Addresser (Addressing IC: SM19522SK) www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 18 of 21...
  • Page 19: Troubleshooting

    — Ensure the input voltage is correct Flickering Incorrect power input/Excess products connected — Ensure the power supplies are not overloaded due to an excess of products connected If problems persist or the product is not working as specified, please contact your Traxon  Technologies office for assistance. www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 19 of 21...
  • Page 20: Warranty Statement

    Warranty Statement Traxon Technologies warrants its Products against material or workmanship defects for a period of  five (5) years from date of invoicing, provided that the purchased items are used under the conditions  stated in this user manual. Please refer for all warranty terms and conditions. www.traxon-ecue.com www.traxon-ecue.com ©2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. Installation Guide 08/23 V1.0 20 of 21...
  • Page 21 Please check for the latest updates and changes on the Traxon website. © 2023 TRAXON TECHNOLOGIES. ALL RIGHTS RESERVED. www.traxon-ecue.com...
