3.2 Rear Panel

3.2.1 DH-XVR51xxH-I/DH-XVR51xxH-I2/DH-XVR51xxH-I3/DH-
XVR51xxH-4KL-I2/DH-XVR51xxH-4KL-I3/DH-XVR51xxHE-I2/DH-
XVR51xxHE-I3/DH-XVR51xxHE-4KL-I2/DH-XVR51xxHE-4KL-I3/DH-
XVR71xxH-4K-I2/DH-XVR71xxH-4K-I3/DH-XVR71xxHE-4K-I2/DH-
XVR71xxHE-4K-I3/DH-XVR71xxHE-4KL-I
Table 3-10 Front panel description
Name
HDD status indicator
Power status indicator
Network status indicator
Figure 3-12 Rear panel
Function
● The indicator is off when the HDD is running
normally.
● The indicator glows blue when the HDD is in
malfunction.
● The indicator is off when the power is connected
abnormally.
● The indicator glows blue when the power is
connected normally.
● The indicator is off when the network connection
is correct.
● The indicator glows blue when the network
connection is abnormal.
23
