Security Center; Security Status - Dahua DH-XVR42 AN-I Series User Manual

Parameter
File Size
Picture Upload Interval (Sec.)
Channel
Day
Period 1, Period 2
Record type
Step 3 Click Test.
The system pops up a message to indicate success or failure. If failed, check the network
connection or configurations.
Step 4 Click Apply to complete the settings.

5.19 Security Center

You can set security options to strengthen device security and use the device in a much safer way.

5.19.1 Security Status

Security scanning helps get a whole picture of device security status. You can scan user, service and
security module status for detailed information about the security status of the device.
Detecting User and Service
Description
Enter the length of the uploaded recorded video.
● If the entered length is less than the recorded video length,
only a section of the recorded video can be uploaded.
● If the entered length is more than the recorded video
length, the whole recorded video can be uploaded.
● If the entered length is 0, the whole recorded video will be
uploaded.
● If this interval is longer than snapshot interval, the system
takes the recent snapshot to upload. For example, the
interval is 5 seconds, and snapshot interval is 2 seconds per
snapshot, the system uploads the recent snapshot every 5
seconds.
● If this interval is shorter than snapshot interval, the system
uploads the snapshot per the snapshot interval. For
example, the interval is 5 seconds, and snapshot interval is
10 seconds per snapshot, the system uploads the snapshot
every 10 seconds.
● To configure the snapshot interval, select Main Menu >
CAMERA > Encode > Snapshot.
Select the channel that you want to apply the FTP settings.
Select the week day and set the time period that you want to
upload the recorded files. You can set two periods for each
week day.
Select the record type (Alarm, Intel, MD, and General) that you
want to upload. The selected record type will be uploaded
during the configured time period.
298
User's Manual
