- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dahua DHI- NVR4116-8P-4KS2 o cerca il tuo prodotto tra le migliori offerte di Videosorveglianza Network Video Recorder Quick Start Guide V1.0.0...
-
Page 2: Foreword
Foreword General This Quick Start Guide (hereinafter referred to be "the Manual) introduces the functions and operations of the NVR devices (hereinafter referred to be "the Device"). Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words Meaning Indicates a potential risk which, if not avoided, could result in... - Page 3 electronic version shall prevail. All the designs and software are subject to change without prior written notice. The product updates might cause some differences between the actual product and the Manual. Please contact the customer service for the latest program and supplementary documentation. ...
-
Page 4: Important Safeguards And Warnings
Important Safeguards and Warnings The following description is the correct application method of the Device. Read the Manual carefully before use to prevent danger and property loss. Strictly conform to the Manual during application and keep it properly after reading. Operating Requirement ... -
Page 5: Table Of Contents
Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................III 1 Checking the Components ........................ 1 2 Installing HDD ............................2 2.1 SMART 1U ............................. 2 2.2 MINI 1U, COMPACT 1U, 1U ......................4 3 Connection ............................. 6 4 GUI Operations ............................ -
Page 6: Checking The Components
Checking the Components All the installation and operations here should conform to the local electric safety rules. The Device does not support wall mounting with the front panel facing down. When you receive the Device, please check against the following checking list. If any of the items are missing or damaged, contact the local retailer or after-sales engineer immediately. -
Page 7: Installing Hdd
Installing HDD The following figures are for reference only. The actual product shall govern. Shut off the power before you replace the HDD. SMART 1U For the first time installation, check whether the HDD has been installed or not. It is recommended to use HDD of enterprise level or surveillance level. - Page 8 Step 4 Turn the device upside down, match the screws with the holes on the HDD and then fasten them. The HDD is fixed to the baseboard. Figure 2-4 Installing HDD (4) Step 5 Connect the HDD data cable and power cable to the device. Figure 2-5 Installing HDD (5) Step 6...
-
Page 9: Mini 1U, Compact 1U, 1U
MINI 1U, COMPACT 1U, 1U For the first time installation, make sure whether the HDD has been installed or not. It is recommended to use HDD of enterprise level or surveillance level. It is not recommended to use PC HDD. Step 1 Remove the fixing screws of the case cover (including the two screws on the rear panel and two screws on the left and right panels). - Page 10 Figure 2-10 Installing HDD (4) Step 5 Connect the HDD data cable and power cable to the device. Figure 2-11 Installing HDD (5) Step 6 Put back the cover and fasten the screws on the rear panel and side panels to complete the installation.
-
Page 11: Connection
Connection Following figures are for reference only. The actual product shall govern. Figure 3-1 1U series connection Check the icons on the rear panel carefully and refer to the actual product for detailed information. If the icon is , input DC 12V power. If the icon is , input DC 48V power. -
Page 12: Gui Operations
GUI Operations Slight difference might be found on the interfaces of different models. Following figures are for reference only. The actual product shall govern. Booting Up Before the boot up, please make sure: The rated input voltage shall match with the device power requirement. Make sure the power wire connection is ready and then turn on the power button. - Page 13 Figure 4-1 Enter password Step 2 Configure the password information for admin. For details, see Table 4-1. Table 4-1 Password information description Parameter Description User By default, the user is admin. In the Password box, enter the password for admin. Password The new password can be set from 8 characters through 32 characters and contain at least two types from number, letter and...
- Page 14 Figure 4-2 Unlock pattern Step 4 Draw an unlock pattern. After setting unlock pattern, the password protection setting interface is displayed. See Figure 4-3. Once you have configured the unlock pattern, the system will require the unlock pattern as the default login method. If you skip this setting, enter the password for login.
-
Page 15: Modifying Ip Address
After configuration, if you forgot the password for admin user, you can reset the password through the reserved email address or security questions. For details about resetting the password, see User’s Manual. If you do not want to configure the settings, disable the email address and security questions functions on the interface. -
Page 16: Registration
Registration Select Main Menu > CAMERA > Registration. The Registration interface is displayed. See Figure 4-5. You can register remote devices through the following two ways: Click Device Search. In the result list, double-click the remote device or select the check box in front of the device, and then click Add to register the remote device. -
Page 17: Playback
Figure 4-6 Schedule Step 2 Configure parameters such as channel, pre-record, ANR and record type. After setting one HDD to be redundant disk, select the Redundancy check box to realize video file backup. It is to save video files to different HDDs at the same time. Once one of the HDDs is damaged, there is still a backup file in another disk to ensure data reliability. -
Page 18: Shutdown
Figure 4-7 Record search Shutdown Click at the top right corner and then select Shutdown. GUI Operations 13... -
Page 19: Web Operations
Web Operations If it is your first time to log in the Device, you shall initialize the Device first. For detailed information, see User’s Manual. Step 1 Open the browser and enter the IP address of the Device into the address bar. Press Enter key. -
Page 20: P2P
Step 1 Scan the QR code with the cell phone to download and install the mobile app. You can get the mobile app QR code and device SN QR code through the following two ways: Log in the local interface and select Main Menu > NETWORK > P2P. ... - Page 21 Figure 6-3 P2P (2) Scan the device label or the device SN on the local interface (NETWORK > P2P) to register the device. See Figure 6-4. Figure 6-4 P2P (3) After scanning, you can view the device SN. Click Start Live Preview and you can see live image on the cell phone.
-
Page 22: Appendix 1 Cybersecurity Recommendations
Appendix 1 Cybersecurity Recommendations Cybersecurity is more than just a buzzword: it’s something that pertains to every device that is connected to the internet. IP video surveillance is not immune to cyber risks, but taking basic steps toward protecting and strengthening networks and networked appliances will make them less susceptible to attacks. - Page 23 Change Default HTTP and Other Service Ports We suggest you to change default HTTP and other service ports into any set of numbers between 1024~65535, reducing the risk of outsiders being able to guess which ports you are using. Enable HTTPS We suggest you to enable HTTPS, so that you visit Web service through a secure communication channel.
- Page 24 The network should be partitioned and isolated according to the actual network needs. If there are no communication requirements between two sub networks, it is suggested to use VLAN, network GAP and other technologies to partition the network, so as to achieve the network isolation effect. ...
