Step 2 Configure the settings for the tampering detection parameters. For details, see "5.10.4.1
Configuring Motion Detection Settings".
For PTZ activation, different from motion detection, the video loss detection can activate
PTZ preset, tour, and pattern.
Step 3 Click Apply to complete the settings.
● Click Default to restore the default setting.
● Click Copy to, in the Copy to dialog box, select the additional channel(s) that you want
to copy the motion detection settings to, and then click Apply.

5.10.5 System Events

You can configure the alarm output for three types of system event (HDD, Network, and User). When
there is an abnormal system event occurs, the system activates alarms in the way that you configure
in this section.

5.10.5.1 Configuring HDD Event Settings

Procedure
Step 1 Select Main Menu > ALARM > Exception > Disk.
Figure 5-127 Video tampering
