Dahua DH-XVR42 AN-I Series User Manual page 257

Step 2 On the humidity information line, click
Step 3 Configure the settings for the following parameters.
Parameter
Access Point
Type
Detect Position Name
Preview Channel
Event Type
Figure 5-205 Temperature/Humidity
Figure 5-206 Setting
Table 5-51 Alarm settings
Description
Indicates the channel that the camera is connected to.
Humidity by default.
Set the detect position name.
Select the channel that you want to preview to help monitor the
channel of access point. This channel could be the channel of
access point or any other channels according to your actual
situation.
Select event type as High Humidity or Low Humidity, and set
241
.
User's Manual
