Graco RATIO KING 231175 Instructions-Parts List Manual

Cart–mounted airless packages

Hide thumbs

page of 16

/ 16
Bookmarks

Quick Links

Download this manual

Instructions – Parts List

Parts

20:1 RATIO AND 28:1 RATIO KINGt CARBON STEEL

Cart–Mounted Airless

Packages

20:1 RATIO KINGt PUMP

2000 psi (138 bar, 14 MPa) Maximum Working Pressure

100 psi (7 bar, 0.7 MPa) Maximum Air Inlet Pressure

Part No. 231175, Series C

With Dura–Flot 2400 Displacement Pump

28:1 RATIO KINGt PUMP

2800 psi (193 bar, 19 MPa) Maximum Working Pressure

100 psi (7 bar, 0.7 MPa) Maximum Air Inlet Pressure

Part No. 231174, Series C

With Dura–Flot 1800 Displacement Pump

Read warnings and instructions.

See page 2 for model numbers and maximum

working pressures.

GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441

308179F

06280
