BACTEC™ FX40
Instrument User's Manual
 
B ecton, Dickinson and Company
7 Loveton Circle
Sparks, Maryland 21152 USA
Benex Limited
Pottery Road, Dun Laoghaire
Co. Dublin, Ireland
Australian Sponsor:
Becton Dickinson Pty Ltd.
66 Waterloo Road
Macquarie Park NSW 2113
Australia
8090414(09) 2021-07
441980
English
bd.com/e-labeling
