Models:
TCT1175
Terra Cotta Termination Cap
This chimney termination cap has been tested for use with specific Hearth & Home Technologies fireplaces. Check with
your local building code agency before you begin installation to ensure compliance with local codes, including the need for
permits and follow-up inspections. If you encounter any problems regarding code approvals, or if you need clarification of
any of the instructions contained here, contact your Hearth & Home Technologies dealer. For the dealer nearest you, please
visit www.hearthnhome.com
Caution! Risk of Cuts/abrasions. Wear protective
gloves and safety glasses during installation. Sheet
metal edges are sharp.
WaRning! Risk of Fire. Intended for use with a
metal chase top only.
Hearth & Home Technologies • TCT1175 Terra Cotta Termination Cap • 4014-035 Rev D • 02/16
tm
Figure 1 TCT1175 Dimensions
Installation
Instructions
Note: An arrow () found in the text signifies change
in content.
1
Advertisement
Related Manuals for Hearth and Home Technologies TCT1175
Summary of Contents for Hearth and Home Technologies TCT1175
- Page 1 WaRning! Risk of Fire. Intended for use with a metal chase top only. Figure 1 TCT1175 Dimensions Hearth & Home Technologies • TCT1175 Terra Cotta Termination Cap • 4014-035 Rev D • 02/16...
- Page 2 Fasten and seal the four ends of the angle. from developing. • Fasten and seal the cap to the angle. • Caulk all screws (or nails) in the chase top. Hearth & Home Technologies • TCT1175 Terra Cotta Termination Cap • 4014-035 Rev D • 02/16...
