DS 9.05 - M2K05 - Micro2000 Controller
August 2013
Approvals
The Micro2000 series controllers conform to:
• Electromagnetic emission and immunity requirements according
to standards EN55011 (CISPR11) and EN50082 for CE Marking and
C-Tick Labelling.

Installation

1. The Micro2000 should be mounted on DIN rail in cabinets
approved for switchgear or industrial control equipment. It
should be mounted in a dry and clean location, free of excess
vibration. Maximum terminal cable entry is 1.5mm² wire.
2. Wire in accordance with INNOTECH connection diagrams and
local bylaws or refer to your local distributor.
3. Connect the 240VAC supply to the correct terminals on the
controller, observing the correct polarity of the connections.
Connect the EARTH to the correct terminals on all units.
4. The maximum wire length between the control station and the
controller should not exceed 50 metres. The wiring between
these devices should not be run in parallel with conductors
carrying high current.
This product should only be installed by qualified personnel.
Fault Representation
1. If the Control Station display reads "HELP", this is due to a
communications error between the Controller and the Control
Station. Check the interconnecting 2 core screened cable
for continuity or short circuits. As a result of this failure the
controller will shutdown after 1 minute.
2. If the Control Station reads "SEN 1 FAIL", this is due to an open
circuit Sensor on Input 1. The fault occurs if an open circuit has
been detected at Input 1 for more than 20 seconds. As a result
of the failure, the controller will shut down. In this mode, the
fan can still be turned on (Vent Mode).
3. If the Control Station reads "SEN 2 FAIL", this is due to an open
circuit Sensor on Input 2. The fault occurs if an open circuit has
been detected at Input 2 for more than 20 seconds. As a result
of the failure, the controller will shut down. In this mode, the
fan can still be turned on (Vent Mode).
4. If the Control Station reads "FAIL", this is due to an open
circuit being detected on Input 1 & 2 at the same time. This is
a generic fault and can be used to shut the controller down
via an external relay (See wiring diagram for more details). As
a result of the failure, the controller will shut down and flash
"FAIL" on the display.
Inputs & Outputs
Universal Inputs
Zone 1 Thermistor (Innotech SENx) and External Start Zone
UI 1
change (Momentary Push Button)
Zone 2 Thermistor (Innotech SENx) and External Start Zone
UI 2
change (Momentary Push Button)
Digital Outputs
DO 1 Fan Low (16A Relay. Common and Normally Open Contact)
DO 2 Fan Mid (10A Relay. Common and Normally Open Contact)
DO 3 Fan High (10A Relay. Common and Normally Open Contact)
DO 4 Cool (10A Relay. Common and Normally Open Contact)
DO 5 Night Zone (2A Relay. Common and Normally Open Contact)
DO 6 Day Zone (2A Relay. Common and Normally Open Contact)
DO 7 Heat (2A Relay. Common and Normally Open Contact)
Inputs
There are two multipurpose inputs which are used as described
below.
The primary use of Input 2 is a 10kΩ Temperature sensor. If one sen-
sor is chosen in Parameter 12, the temperature sensed on input 2 is
used to control both zones (Day and Night). If two sensors are chosen
then Input 2 is used for the Night Zone and Input 1 for the Day Zone.
Both Inputs have multiple uses. If two sensors are chosen, both
inputs can be used as momentary push buttons as well as 10kΩ
Sensors. These push buttons are used as an external way to start the
controller as well as changing the zone to be controlled.
For example: a push button can be placed in the main bedroom of
the House/Apartment. This enables the user to start the controller
and change the zone without having to walk to the main Control
Station.
It will not stop the system if it is already running. It is only for
external start and changing the zone.
If one sensor is chosen in Parameter 12, then only Input 2 can use the
momentary push button start.
Push Buttons
The normal control button use is described below:
1.
2.
3.
4.
Time Clock Mode
When Parameter 9 is set to "On", the Time button allows you to
enable or disable the Time Clock. Any Schedules that have been
programmed will not function unless the Time LED is On. When
the Time button is pressed, the current time is displayed for 5
seconds and then reverts back to the current temperature.
Timer Mode
When Parameter 9 is set to "Off", the Time button is used as a
adjustable On or Off timer. When pressed, the display will show
the time in hours before the controller will change state.
0.1 hours = 6 minutes.
If the unit is off, the controller will display the time till the unit
will turn on. If the unit is on, it will display the time it will turn
off.
The time displayed may be adjusted by pressing the
buttons until you have adjusted to the time required. If no
buttons are pressed for 5 seconds, the display will revert back to
the current temperature. When the timer has been set, the Time
LED will be lit.
In Timer Mode, the Automatic Day / Night Change Over
functionality is not available.
5.
selected.
If the controller has been turned on by the Time Clock
Schedule, the
next scheduled "On" time. Similarly, if the controller is Off,
the
scheduled "Off" time.
© MASS ELECTRONICS Pty Ltd 2008
The "Fan" button is used to change the current fan
speed. The fan speed is indicated by 3 LEDs above the
button. If the controller is not running (Off), the Fan
button can be used to turn the Fan on only (Vent Mode).
The "Mode" button allows you to change the mode of
the controller between Auto, Heat and Cool.
The "Zone" Button allows you to change which zone is
to be Air Conditioned. Pressing the button toggles
between each of the zones. When "On" is selected in
Parameter 11 (Enable Both Zones), both zones can be
turned on at once.
When this occurs, the controller will use the average of
both sensors and the Day Setpoint to maintain
temperature. This only occurs when there are two
sensors fitted and/or two setpoints chosen.
This button has two selectable modes of operation. The
operation of the button can be changed by using
Parameter 9 to either Time Clock mode or Timer mode.
The On / Off button is used to change the current state
of the controller. It can be used to override either the
Time Clock or Timer depending on which mode is
is used to force the controller off till the
can be used to force the controller on until the next
and
