Appendix; Technical Specifications - Cadac C Series Hardware Overview

Appendix

Technical Specifications

General Specifications
Faders
Screens
PSU
Inputs
Channels
Busses
Matrix
Outputs
Graphic EQ
Internal FX
Local IO
Comms
20 x 100mm motorised faders
1 x 23.5" 16:9 HD / 1 x 6.5"
2 x internal PSUs
Up to 192 (inc local I/O)
96 with full processing
48 configurabl e in pai rs as group / aux/ st aux plus
dedicated LCR, monitor LR, headphones LR and talkback
Up to 67 x 48 with full processing
Up to 192 (inc. local I/O)
32 band +/-16 dB on all 55 outputs
16 high -resolution 96 kHz stereo effects processors
16 x XLR Mic Inputs (inc 48 V, PAD and 1 dB gai n steps),
8 x XLR Balanced outputs,
4 x XLR AES/EBU inputs and 4 x XLR AES/EBU outputs
2 x Cadac MegaCOMMS on:
o
4 x BNC
o
2 x Duplex optical LC ports
CM-J50_22-01-2024_Iss-1
Page. 125 / 129
