OPERATION AND INSTALLATION MANUAL
WOODSTOVE & SMOKE EXEMPTION MODEL
CHURCHILL 8 CONVECTION DUAL CONTROL
Churchill 8 Convec�on
DC
Churchill 8 Convec�on
DC SE
Churchill 8 Convec�on
Logstore DC
Churchill 8 Convec�on
Logstore DC SE
1 of 24
M00824-00-00-00-06
M00827-00-00-00-00
M00826-00-00-00-06
M00828-00-00-00-00
ENG
Dec 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CHURCHILL 8 CONVECTION DUAL CONTROL and is the answer not in the manual?

Questions and answers

Related Manuals for Mendip Stoves CHURCHILL 8 CONVECTION DUAL CONTROL

Summary of Contents for Mendip Stoves CHURCHILL 8 CONVECTION DUAL CONTROL

  • Page 1 Dec 2023 OPERATION AND INSTALLATION MANUAL WOODSTOVE & SMOKE EXEMPTION MODEL CHURCHILL 8 CONVECTION DUAL CONTROL Churchill 8 Convec�on M00824-00-00-00-06 Churchill 8 Convec�on M00827-00-00-00-00 DC SE Churchill 8 Convec�on M00826-00-00-00-06 Logstore DC Churchill 8 Convec�on M00828-00-00-00-00 Logstore DC SE 1 of 24...
  • Page 2 DIMENSIONS (mm) - CHURCHILL 8 DC DIMENSIONS (mm) - CHURCHILL 8 DC LOGSTORE The direct air intake spigot (80mm diameter) to the rear of the stove is removable with a 2.5mm Allen key. 2 of 24...
  • Page 3 This manual refers to the stoves listed above, which are tested in accordance with EN 13240. Thank you for purchasing your new stove from Mendip Stoves. Please read this manual carefully to ensure that you get maximum enjoyment and performance from your new stove and to prevent any poten�al opera�onal problems. Please note that “all local regulations, including those referring to na�onal and European Standards, need to be complied with when...

  • Page 4: Health And Safety Precautions

    IMPORTANT: These instruc�ons cover the basic principles to ensure the sa�sfactory installa�on of Mendip Stoves product :- Churchill 8 DC models, although detail may need slight modifica�on to suit par�cular local site. In all cases the installa�on must comply with current Building Regula�ons, Local Authority Byelaws and other specifica�on or regula�ons as they affect the installa�on of the stove.
  • Page 5 Older proper�es, especially, may have chimney faults or the cross sec�on may be too large. Mendip Stoves recommend the use of a solid fuel flue lining system for all installa�on into existing chimneys. All chimney systems must be used in accordance with Building Regulations Approved Document J.
  • Page 6 STOVE PERFORMANCE & TESTING CHURCHILL 8 CONVECTION DC Mendip Stoves, The Churchill 8 DC models are tested in accordance with EN 13240. Suitable for use in Output Efficiency CO@13% O₂ Smoke Wood Fuel Control Zones Churchill 8 DC 7.5 kW Yes / SE model 79.3%...
  • Page 7 MINIMUM DISTANCE TO NON-COMBUSTIBLE MATERIALS The stove can be recessed in a suitable sized non - combus�ble fireplace but a permanent free air gap of at least 50mm must be le� around the sides, the top and the back of the stove; this is to facilitate a reasonable heat output and allows access to the stove for removal and maintenance.
  • Page 8 HOW TO FIT A LOGSTORE LEGS- Loxton -Churchill - Woodland Remove internals and top plate Unbolt stove adjustable legs with 13mm spanner Ensure leg is aligned with body before final tighten Place stove on side to allow leg installation, protect paint with a blanket Use M8 x 50mm bolts supplied and fix legs in place, use...
  • Page 9 HOW TO FIT LOGSTORE HEAT SHIELD Place stove on its side with brick set and loose parts removed. Screw in 4 x 15mm standoffs into base convection panel Standoff Place addi�onal log store convector panel in place Screw in 4 x 5mm x 12mm hex bolts into standoffs fixing 9 of 24...

  • Page 10: Commissioning And Handover

    Connec�on to chimney Mendip Stoves are built with a top flue outlet as standard, this can be altered to a rear connec�on by removing the top collar, rear cover plate then exchanging collar and plate. Care should be taken to ensure an air�ght fit when refi�ng collar and plate.
  • Page 11 OPERATING YOUR STOVE - CHURCHILL 8 DUAL CONTROL THE CHURCHILL 8 STOVE HAS THREE AIR CONTROL LEVERS TO HELP REGULATE YOUR STOVE. PRIMARY AIR SECONDARY AIR TERTIARY AIR Pull out for more Pull out for more Pull out for less air , push in close air , push in close air , push in for...
  • Page 12 HOW TO LIGHT YOUR WOODBURNING STOVE Note: If the chimney is externally fi�ed or the stove has been installed on a larger diameter clay chimney liner then on cold days it maybe necessary to warm the flue using firelighters prior to ligh�ng with wood. 1.

  • Page 13: Warning Note

    DO NOT BURN HOUSE COAL. DO NOT BURN HOUSEHOLD WASTE. THIS APPLIANCE IS NOT AN INCINERATOR MENDIP STOVES RECOMMEND THE USE OF A FLUE THERMOSTAT TO CHECK YOUR STOVE IS NOT OVERHEATING. PLACE FLUE THERMOSTAT DIRECTLY ABOVE COLLAR OF STOVE AND REFER TO TEMPERATURE GAUGE ON PAGE 6.

  • Page 14: Troubleshooting

    RE-FUELLING WHEN BURNING WOOD Adding fuel to your stove when you only have glowing embers,and the flames have died down, is the cleanest way to refuel your stove. 1. Before refuelling, Pull open both the Primary and Secondary controls fully. 2.

  • Page 15: Maintenance

    MAINTENANCE Mendip stoves recommends that your model needs to have the ash removed from the stove at regular intervals (weekly if used daily). Allowing the ash pan to over flow can impede the func�on of the stove and can cause possible damage to the stove grate and ash pan.

  • Page 16: Overnight Burning

    The SE appliances include a modified air control to prevent closure of the secondary air control beyond 25% open, altera�ons should not be a�empted . Mendip Stoves smoke control stoves should not be burnt with the door le� open. The refuelling procedure : Allow the newly charged fuel to burn with the secondary air control set at maximum for up 3 to 4 minutes.

  • Page 17: Loose Parts

    STOVE PARTS, COMBUSTION CHAMBER, ASSEMBLY This sec�on shows the parts contained in your stove, each stove has over 80 spare-parts and, each part is detailed. When new parts are required the sec�on will allow spares to be recognised and ordered. As a further source of reference please visit www.eurostove.co.uk for latest spare-part informa�on.
  • Page 18 HOW TO REMOVE THE WOOD BURNER INTERNAL PARTS To remove the vermiculite brick set take the following steps: Li� out rear brick spacer fuel Li� out the 4 retaining bars. base bricks next to the grate. Remove le� hand vermiculite side brick by li�ing the top baffle brick and pulling the side brick down from the top.
  • Page 19 VERMICULITE BRICK SET PART NUMBERS Item Number Descrip�on Quan�ty Weight (G) ES-800-400-3 COMPLETE BRICK SET 7264 ES-800-415-1 LH SIDE BRICK ES-800-414-1 RH SIDE BRICK ES-800-417-1 BASE SIDE BRICK ES-800-421-0 LH SPACER (METAL) 1490 ES-800-422-0 RH SPACER (METAL) 1490 ES-800-420-0 BASE BRICK FRONT AND REAR ES-800-425-0 BAFFLE ES-500-430-0...
  • Page 20 DOOR ASSEMBLY - (Complete CH-500-300-0) Diagram No. Part No. Descrip�on CH-500-209-0 Door Handle CH-500-120-0 Glass Clamp CH-500-201-0 Door Frame (only) M90502-01-01-99-03 Curved Door Glass M90520-06-02-01-05 Door Rope Seal Kit M90520-06-13-99-02 Handle Fixing Kit (complete) M90026-01-02-01-04 Glass Seal Kit (incl. 6 Clamp Pads) U91000-98-12-99-00 M5 X 8mm screw (6) CH-500-129-0...
  • Page 21 CHURCHILL 8 CONVECTOR DC SIDE PANELS & LOG STORE Descrip�on Diagram No. Part No. ES-800-119-0 Flue Cover Plate CH-800-110-0 Top Plate CH-800-602-0 Inner Ven�lator Panel CH-800-145-0 Inner Heat Deflector CH-800-127-0 Top Bracket M10530-20-08-99-00 M5 x 12mm Countersunk Hex Head Screw CH-800-118-0 Side Panel CH-800-115-0...
  • Page 22 STOVE PART NUMBERS See page 19 See page 20 22 of 24...
  • Page 23 STOVE PART NUMBERS Diagram No. Part No. Descrip�on ES-500-187-0 Top Flue Rear Convec�on Panel M9800-07-06-00-02 150 mm Flue Collar M90800-07-03-00-02 Flue Cover Plate M90800-07-10-01-00 Collar/Blanking Plate Seal ES-500-142-0 Flue Blanking Plate ES-500-180-1 Secondary Air Smoke Deflector ES-500-117-1 Turbulence Plate ES-300-208-0 Grate ES-500-147-0 Grate Support...
  • Page 24 Mendip Stoves Ltd. Unit H1, Mendip Industrial Estate Mendip Road, Rooksbridge Somerset. BS26 2UG Website: www.mendipstoves.co.uk Email: info@eurostove.co.uk CODE: M10820-49-00-99-00 Churchill 8 Convector DC Manual - Version 3 - Dec 2023 24 of 24...
