OPERATION AND FUNCTIONS
5.2.3 Copying flat or locker keys
See Figure 9
- Secure the keys in side 3 of the clamps.
- Turn the machine on and, while holding the carriage
assembly by the motion control lever (8), move the keys
towards the cutter (1) and tracer (2).
- Push the handle (6) back inwards to disable clamp carriage
assembly rotation, previously setting clamp carriage assem-
bly rotation to an intermediate position.
- We recommend working slowly, without forcing the cutter.
- If the duplication process produced any burrs on the copy,
these can be removed using the brush that is provided with
the machine for this purpose.
13
13
EN
