- Page 1 ASSEMBLY MANUAL Evolve Corner Far Infrared Sauna...
-
Page 2: Pre-Assembly Checklist
Pre-Assembly Checklist Selecting a suitable location For best results, please place your sauna on a flat level surface. Suitable locations could include the garage, bedroom, sunroom. The sauna can be placed on carpet, tiles, timber flooring or concrete. Outdoor Placement For outdoor placement please note that the sauna must go in a covered area to provide protection from direct rainfall, additionally the sauna must be protected by one of our Australian made covers to protect the warranty. - Page 3 Prepare the Floor Base If you are assembling your sauna on a hard surface floor, it is recommended that you apply the included adhesive felt pads to the bottom of the Floor Base, 3 on each corner and along the runner strips of wood.
- Page 4 Remove Heater Guards Remove the magnetic heater guards from the 2 large Back Walls and 2 small Front Walls Right Back Wall Position the Right Back Wall into the channel of the Floor Base. Shift the wall fully towards the back corner of the Floor Base. Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 5 Left Back Wall Place the Left Back Wall into the Floor Base channel. Connect Back Corner Connect the Right Back Wall to the Left Back Wall by raising the Right Right Back Wall Right Back Wall Back Wall approx. 1/2" then sliding down to connect the 2 fasteners.
- Page 6 Power Cord After installing the 2 Back Walls, decide which of the exit holes you wish to use for the power cord. Feed the main power cord through the chosen exit hole in the Back Wall. DO NOT PLUG THE POWER CORD INTO YOUR WALL OUTLET AT THIS TIME Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 7 Prepare the Front Door Wall Ensure that the circular connector is pulled out from within the Door frame. Stuffing a bit of plastic wrap in to the door frame temporarily to hold the connector out may be helpful Front Door Wall Place the Front Door Wall in the Floor Base channel.
- Page 8 Side Wall Glass Panel Install the Side Wall Glass Panel with the etching on the glass facing to the interior of the sauna while second person stabilizes the Front Door Wall holding it upright. Glazing Strip A small wooden wedge is Insert the flexible glazing included to help push the strip into the channel of the...
-
Page 9: Right Side
Connect Back Right Corner Connect the Right Side Wall to the Right Back Wall by raising the Right Side Wall approx 1/2" then sliding down to connect the fasteners Cinch the two walls together by applying pressure on the outside of the Right Side Wall with the inside of your knee. - Page 10 Left Side Wall Repeat the same procedure used to assemble the Right Side Wall for the Left Side Wall Install Left Side Glass Panel Insert glazing strip into door frame channel Position the Left Side Wall Connect the Left Back Corner NOTE: IT IS ESSENTIAL THAT THE HELPER CONTINUES TO HOLD AND KEEP THE FRONT DOOR WALL UPRIGHT.
- Page 11 Wrap the Entire Sauna Use the provided roll of plastic wrap to encircle the entire sauna 3X around. Once wrapped, there is no need for the helper to continue supporting the front wall. Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 12 Prepare the Roof Pull the plastic connector down and out of the roof before lifting the roof into place. If you are unable to grab hold of the connector through the small opening in the ceiling, it may be necessary to remove the first T&G board on the left side of the roof and feed the connector down through the opening.
- Page 13 Left Side Leg Heater Install Left Side Leg Heater by sliding it down into holding brackets on walls Leg Heater Connection Connect the power supply lead from the Left Leg Heater to the Right Leg Heater as shown Right Side Leg Heater Install Right Side Leg Heater by sliding it down into holding brackets Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 14 Under-Bench Electrical NOTE: Do not connect main power cord to your wall outlet at this time. Connect the circular connector to Power Attach the 'D-Sub' computer Supply Box. Align the groove in black plastic style connector as shown. connector with the ridge in the power box connector.
- Page 15 Grounding Wire Connect the yellow grounding wire from bottom side of the Left Bench to the yellow Left Bench grounding wire from the Power Supply Box. Position the Left Bench as shown Lower the Left Bench into position Grounding Wire Right Bench Connect the yellow grounding wire from Position the Right Bench as shown...
- Page 16 Door Heater Connection Connect the Door Heater coiled wire to Heater Guards the Door Frame. Align the groove in the Reinstall the magnetic Heater Guards on black circular connector with the ridge the 4 Walls inside the Door Frame Connector Install the Door Knob Install the 4 furniture bolts Install the remaining...
- Page 17 Heater Guards The heater guards in your new Sun Stream Infrared Sauna are held to the wall with strong earth magnets. If preferred, the heater guards can be screwed directly to the wall for a more permanent and secure attachment. The heater guards are pre-drilled for the attachment screws.
- Page 18 Drill a pilot hole into the wall through the holes in the heater guards.Do not drill deeper than necessary for the length of the screw. NOTE: The pilot holes are important to ensure that the tongue and groove wall boards do not split when installing screws.
- Page 19 Option-L Movable Bench Assembly Connect bench legs to the inside corners of the frames using supplied Ensure that the legs' ends are flush wood screws. with the bottom edge of the frames Attach the leg assembly to the bottom of the bench surface.Choose which surface of the bench you prefer to be the top and bottom.
-
Page 20: Cup Holder
Infrared heater panels. Cupholder Many of our customers simply set the cup holder on the bench of the sauna. In the Evolve 10, 20 and 30 saunas, the cup holder can be mounted on the side wall under the heater panels. Be sure to drill pilot holes first for the wood screws to mount cup holder to the T&G wall boards.
