Summary of Contents for Sun-Stream evolve 10
- Page 1 Assembly Manual Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 2 Prepare & Position the Sauna Floor If you are assembling your sauna on a hard surface floor it is recommended that you apply the included adhesive felt to the bottom of the sauna floor. Place the sauna floor in the desired location. It is necessary to position the floor out from your walls for assembly and slide the sauna into final position following assembly.
- Page 3 Before installing the Front Wall, ensure that the door heater electrical is protruding from bottom of Front Wall frame A bit of plastic wrap can serve to hold the connector out slightly. Position the Front Wall Lift the front wall into position carefully lowering the bottom of the wall into the channel on the floor base.
- Page 4 Connect door heater electrical lead to the floor base. Ensure hat the threaded cuff is fully screwed onto the floor base connector. NOTE: Be sure that the wire's connector is fully inserted into the floor base connector and that the threaded cuff is fully screwed onto the floor base connector.
- Page 5 Connect Side & Front Wall Cinch the two walls together by applying pressure on the outside of the side wall with your knee Slide the side wall upward approx. 3/4” while holding the front wall down It is helpful if a second person applies pressure against the opposite edge of the front wall.
- Page 6 Check to ensure that both sets of fasteners have connected by looking at the corner inside of the sauna. It is possible to connect one set of fasteners and miss the other. If there is an obvious gap in the corner between the two walls the fasteners have not connected and the raising and lowering procedure will need to be repeated.
- Page 7 Position Left Side Wall Lift the Left Side Wall into position, wedging the bottom of the wall into the channel in the floor base. Repeat the raising up and sliding down procedure again to connect the Left Side wall to Back Wall and the the Left Side Wall to the Front Wall.
- Page 8 Prepare to install the sauna roof Pull the single plastic connector down and out of the roof before lifting the roof into place. If you are unable to grab hold of the connector through the small opening in the ceiling, it may be necessary to remove the first T&G board on the top left side of the roof and feed the connector down through the opening.
- Page 9 This wire brings power to the roof for the stereo and lighting components Connect Roof Wires Before lowering the roof, connect the 12 V power supply wires. This is easiest accomplished with one person holding the weight of the roof while the other snaps together connectors and then feeds the connector up into roof.
- Page 10 Plug in all heater leads to receptacles in the power supply box. Feed the main power supply cord in through the hole in back wall and insert in power supply box. DO NOT plug power cord into your wall outlet until all electrical connections are complete inside of the sauna.
- Page 11 Power Supply Cord Feed the main power supply cord in through the hole in back wall and insert in to the power supply box. Connect main power cord to your wall outlet when all electrical connections inside of the sauna and the roof are complete. Chromatherapy The Chromatherapy LED panel is controlled by the...
- Page 12 Remove Side Wall Heater Guards The wooden lattice work in front of the heaters is referred to as the heater guard. These are held on with strong magnets. It is necessary to remove the heater guards from the two side walls in order to install the leg heater and the sauna bench.
- Page 13 Install Bench The bench in your new sauna is reversible. Choose whichever side appeals to you to face upward. Reinstall the side wall heater guards Install the door handle Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 14 Heater Guards The heater guards in your new Sun Stream Infrared Sauna are held to the wall with strong earth magnets. If preferred, the heater guards can be screwed directly to the wall for a more permanent and secure attachment. The heater guards are pre-drilled for the attachment screws.
- Page 15 Drill a pilot hole into the wall through the holes in the heater guards.Do not drill deeper than necessary for the length of the screw. NOTE: The pilot holes are important to ensure that the tongue and groove wall boards do not split when installing screws.
- Page 16 Option-L Movable Bench Assembly Connect bench legs to the inside corners of the frames using supplied Ensure that the legs' ends are flush wood screws. with the bottom edge of the frames Attach the leg assembly to the bottom of the bench surface.Choose which surface of the bench you prefer to be the top and bottom.
- Page 17 Floor Heater and General Maintenance Sweat Always sit on a towel on the sauna bench and wipe yourself down with a small towel to contain your sweat. This will minimize staining of the wood surfaces in the sauna. It is inevitable that you will drip some sweat down through the floor grate and on to the floor heater panel.
- Page 18 CAUTION: DO NOT use LARGE towels on the floor heater that cover any more than 30% of the floor heater. SMALL towel only. Floor Heater Cleaning Simply tilt the floor grate up to access the floor heater. Gently wipe the heater with a damp cloth to clean.
- Page 19 Audio System Music can be piped to the speakers in the sauna two different ways, either wireless via the Bluetooth receiver or by directly connecting your device (smart phone, tablet, laptop etc.) with a 3.5mm male to male audio cord. 1.
- Page 20 2. Direct Connect Mode (NO Bluetooth) First, remove the access panels from the roof by unscrewing wood screws. Connect your device to the sauna's audio system by inserting a 3.5 mm male to male audio cord into the BT circuit board as shown (Audio cords not included).
- Page 21 Reinstall the roof panels and feed your audio cord through the hole in roof. Enjoy your favorite audio while relaxing in your new sauna! Australia - 1800 316 962 | New Zealand 0800 21 8020...
-
Page 22: Control Panel
Control Panel Australia - 1800 316 962 | New Zealand 0800 21 8020... - Page 23 Interior Control Panel Temperature Sensor FRAGILE DO NOT TOUCH Australia - 1800 316 962 | New Zealand 0800 21 8020...
- Page 24 Connecting the sauna to your house power supply When the sauna is plugged into you wall outlet the red Power Indicator light on the control panel will be on. The Bluetooth audio receiver on the roof will make a beeping noise its indicator light will turn ON/OFF for Heaters Push the POWER button to turn the sauna heaters ON.
- Page 25 Thermometer /Thermostat Display When the POWER button is turned ON the digital display will show the Thermometer reading. Anytime the + and - buttons are pushed the Thermostat setting display will show. After setting the thermostat the display will return to displaying Thermometer reading. Temperature Control When the interior air temperature is below the Thermostat set temperature, the heaters will remain ON.
- Page 26 Infrared heater panels. Cupholder Many of our customers simply set the cup holder on the bench of the sauna. In the Evolve 10, 20 and 30 saunas, the cup holder can be mounted on the side wall under the heater panels. Be sure to drill pilot holes first for the wood screws to mount cup holder to the T&G wall boards.
- Page 27 Enjoy your new Sun Stream 'Evolve' Infrared Sauna Australia - 1800 316 962 | New Zealand 0800 21 8020...
