Master Trac
Bench
430867 Slate Rift
430868 Glacier White
432068 Spiced Mahogany
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Call us at 1-855-854-7465
or vist us at
www.sauder-closets.com
Lot #: 595150
04/21/23
Purchased: ____________________
Advertisement
Related Manuals for Sauder Master Trac 430867
Summary of Contents for Sauder Master Trac 430867
- Page 1 Bench 430867 Slate Rift 430868 Glacier White 432068 Spiced Mahogany NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Call us at 1-855-854-7465 or vist us at www.sauder-closets.com Lot #: 595150 04/21/23 Purchased: ____________________...
-
Page 2: Table Of Contents
Safety ........10 Warranty ........11 HARDWARE USAGE GUIDE Caution Risk of damage or injury. CONNECTORS must be completely tightened. CONNECTORS that are not Shoulder The shoulder completely tightened may must rest on the loosen, and parts surface. may separate. Page 2 www.sauder-closets.com... -
Page 3: Part Identification
While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help identify similar parts. RIGHT END LEFT END BACK BOTTOM TOE KICK HARDWARE IDENTIFICATION CONNECTOR DOWEL - 16 www.sauder-closets.com Page 3... -
Page 4: Assembly Steps
(14 used) Push fourteen CONNECTOR DOWELS into the exact holes shown in the ENDS (A2 and B2) and TOP (C) until the shoulder of each CONNECTOR DOWEL restsW on the surface of the ENDS and TOP. Page 4 www.sauder-closets.com... - Page 5 E C T S u r i t h o f a c E C T S u r Rounded edge Fasten the ENDS (A2 and B2) to the TOP (C). Tighten four CONNECTORS. www.sauder-closets.com Page 5...
- Page 6 Unfinished edge S u r f a c i t h Rounded edge Turn your unit onto its front edges. Fasten the BOTTOM (E) to the ENDS (A2 and B2). Tighten four CONNECTORS in the BOTTOM. Page 6 www.sauder-closets.com...
- Page 7 Tighten four CONNECTORS in the BACK (D). Place the CONNECTORS in the BACK (D) onto the CONNECTOR DOWELS in the ENDS (A2 and B2). Carefully turn your unit onto its TOP. Tighten four CONNECTORS in the BACK (D). www.sauder-closets.com Page 7...
- Page 8 Push the TOE KICK (F2) onto the CONNECTORS in the ENDS(A2 and B2). Tighten four CONNECTORS. Page 8 www.sauder-closets.com...
- Page 9 Carefully stand your unit upright. NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with a damp cloth. Wipe dry. www.sauder-closets.com Page 9...
-
Page 10: Safety
• Children climbing or hanging on the • Risk of injury or death. • Do not allow children to climb or hang shelves or clothing bars. on the shelves or clothing bars. Avoid placing items like toys or candy on shelves. Page 10 www.sauder-closets.com... -
Page 11: Warranty
Return of any defective Product may be required by Products; (2) abuse or neglect; (3) any commercial, rental or non- Sauder™ Closets, or we may elect to examine the product at its residential use of the Products (including the installation and use location. - Page 12 Trust Sauder Sauder has been making wood products since 1934. Today we offer a wide range of products, mostly made right here in Archbold, Ohio, and supported by our award-winning customer service. Sauder™ Closets are supported by our Limited Lifetime Warranty and offers the same made-in-the-USA advantages as the rest of our product line.
