Base Cabinet
HomePlus Collection | Model 411591
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Store behind
closed doors.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-16
Français pg 17-18
Español pg 19-20
Lot # 532704
08/15/19
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the HomePlus 411591 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder HomePlus 411591

Summary of Contents for Sauder HomePlus 411591

  • Page 1 HomePlus Collection | Model 411591 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-16 Hammer Not actual size Français 17-18 Español 19-20 Skip the power trip. Safety 21-22 This time. Warranty Page 2 411591 www.sauder.com/services...
  • Page 3 Use this part identifi cation to help identify similar parts. RIGHT END (1) LEFT END (1) TOP (1) BOTTOM (1) BACK (1) DOOR (2) ADJUSTABLE SHELF (1) FRONT SKIRT (1) TOP MOLDING (1) SIDE SKIRT (2) www.sauder.com/services 411591 Page 3...

  • Page 4: Table Of Contents

    BLACK 9/16" LARGE HEAD SCREW - 2 BLACK 1-7/8" FLAT HEAD SCREW - 5 SILVER 1-1/8" FLAT HEAD SCREW - 2 BLACK 1/2" FLAT HEAD SCREW - 8 BLACK 9/16" WAFER HEAD SCREW - 4 BLACK 7/8" MACHINE SCREW - 4 Page 4 411591 www.sauder.com/services...
  • Page 5 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push four SAUDER TWIST-LOCK® å FASTENERS (7F) into the large holes in the ENDS (A and B).
  • Page 6 TWIST-LOCK® FASTENERS. Do not stand the unit upright without the BACK fastened. The unit may collapse. ® How to use the SAUDER TWIST-LOCK FASTENER 1. Insert the dowel end of the FASTENER into the hole of the adjoining part. NOTE: The dowel end of the FASTENER must remain fully inserted in the hole of the adjoining part while locking the FASTENER.
  • Page 7 BLACK 1-7/8" FLAT HEAD SCREWS (2S). Remember: Righty tighty. Lefty loosey. Rounded edge U n fi n i s h s u r f a c BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 411591 Page 7...
  • Page 8 The RUBBER SLEEVE will be a tight fi t. Then, fasten the TIE PLATE (3G) to the TOP MOLDING (J). Use å a BLACK 9/16" LARGE HEAD SCREW (1S). BLACK 9/16" LARGE HEAD SCREW (1 used for the TIE PLATE) Wide edge Page 8 411591 www.sauder.com/services...
  • Page 9 Slide the FEET (31E and 32E) into the notches in the SKIRTS (H and R). å Use a hammer to drive a PROPEL NUT (14M) into the holes in the FEET (31E å and 32E). Now, turn an ADJUSTABLE GLIDE (18E) into each PROPEL NUT. (4 used) www.sauder.com/services 411591 Page 9...

  • Page 10: Glide

    NOTE: To raise a corner of the unit, turn the ADJUSTABLE å GLIDE counter-clockwise. To lower a corner, turn the ADJUSTABLE GLIDE clockwise. BLACK 9/16" WAFER HEAD SCREW (4 used in this step) Page 10 411591 www.sauder.com/services...

  • Page 11: Nail

    "square". Fasten the BACK (E) to your unit using the NAILS (1N). å NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. NAIL (30 used in this step) www.sauder.com/services 411591 Page 11...

  • Page 12: Black 1-7/8" Flat Head Screw

    Step 8 Fasten two HINGES (13H) to each DOOR (F). Use eight å BLACK 1/2" FLAT HEAD SCREWS (11S). BLACK 1/2" FLAT HEAD SCREW (8 used for the HINGES) Page 12 411591 www.sauder.com/services...

  • Page 13: Black 7/8" Machine Screw

    Fasten a PULL (97K) to the DOOR (F). Use two BLACK å screw 7/8" MACHINE SCREWS (37S). Repeat this step for the other DOOR (F). å Hinge See the next step for DOOR adjustments. å BLACK 7/8" MACHINE SCREW (4 used for the PULLS) www.sauder.com/services 411591 Page 13...
  • Page 14 To adjust the DOORS in or out (depth), loosen the mounting screw å one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 14 411591 www.sauder.com/services...
  • Page 15 TOP (C) and into the BOTTOM (D). NOTE: The holes in the TOP are not through holes. Use a å little extra force while turning these SCREWS. SILVER 1-1/8" FLAT HEAD SCREW (2 used in this step) www.sauder.com/services 411591 Page 15...
  • Page 16 And to celebrate, why not share your success story? BLACK 1-7/8" FLAT HEAD SCREW (1 used into a stud in your wall) BLACK 9/16" LARGE HEAD SCREW (1 used into the top of your unit) (4 used) Page 16 411591 www.sauder.com/services...
  • Page 17 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 18E PATIN RÉGLABLE ............4 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 31E PIED ARRIÈRE ..............2 en ce qui concerne cet DESSUS ................1 32E PIED AVANT..............2 élément, faire référence...
  • Page 18 TÊTE PLATE 13 mm (11S). Pour commencer l'assemblage, enfoncer quatre FIXATIONS TWIST-LOCK® SAUDER (7F) dans les gros trous des EXTRÉMITÉS (A et B). Répéter cette étape ÉTAPE 9 pour le DESSUS (C). REMARQUE : Ne pas serrer les FIXATIONS TWIST-LOCK® à ce stade Relever, avec précaution, l'élément dans sa position verticale.
  • Page 19 Si EXTREMO IZQUIERDO ..........1 31E PATA POSTERIOR ............2 necesita ponerse en PANEL SUPERIOR ............1 32E PATA DELANTERA ............2 contacto con Sauder en FONDO .................1 SUJETADOR TWIST-LOCK® ........ 7 cuanto a esta unidad, refi érase al número DORSO .................1 MÉNSULA DE SEGURIDAD .........1...
  • Page 20 DE CABEZA PERDIDA de 13 mm (11S). Para comenzar el ensamblaje, empuje cuatro SUJETADORES TWIST-LOCK® SAUDER (7F) dentro de los agujeros grandes de los EXTREMOS (A y B). Repita PASO 9 este paso para el PANEL SUPERIOR (C).
  • Page 21 TOUJOURS décharger les tablettes et les tiroirs, en commençant par les surface supérieures, avant de déplacer le meuble. NE JAMAIS pousser ou tirer un meuble sur de la moquette. Demander à une autre personne de le soulever correctement pour le déplacer et/ou le repositionner. www.sauder.com/services 411591 Page 21...
  • Page 22 SIEMPRE descargue los estantes y cajones, empezando con las superfi cies superiores, antes de moverlo. NUNCA empuje ni tire de los muebles sobre una alfombra. Obtenga que un amigo le ayude a levantarlo correctamente para moverlo y/o reposicionarlo. Page 22 411591 www.sauder.com/services...
  • Page 23 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
