Linen Tower
Model 414819
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-445-1527.
Share your journey!
A little "bonjour" for
your bathroom.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-25
Lot #: 501736
Date Purchased: __________________
04/07/17
Be sure to give us a ring before
making any returns. 1-800-445-1527

Advertisement

loading
Need help?

Need help?

Do you have a question about the Linen Tower 414819 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder Linen Tower 414819

Summary of Contents for Sauder Linen Tower 414819

  • Page 1 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. FUTURE REFERENCE. Prefer the phone? Call 1-800-445-1527. English pg 1-18 Français pg 19-21 Español pg 22-25...
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-18 Hammer Not actual size Français 19-21 Español 22-25 Skip the power trip. Safety This time. Warranty Page 2 www.sauder.com 414819...
  • Page 3 UPPER LEFT END (1) TOP (1) UPPER BACK (1) MOLDING (2) ADJUSTABLE SHELF (3) SHELF (1) LOWER LEFT END (1) LOWER BACK (1) LOWER RIGHT END (1) BOTTOM (1) DOOR (1) LEFT FRONT LEG (1) RIGHT FRONT LEG(1) 414819 www.sauder.com Page 3...
  • Page 4 RUBBER SLEEVE - 12 FURNITURE TIPPING RESTRAINT KIT - 1 BLACK 1-1/2" FLAT HEAD SCREW - 12 BLACK 1/2" PAN HEAD SCREW - 10 BLACK 7/8" MACHINE SCREW - 1 SILVER 1/2" FLAT HEAD SCREW - 4 Page 4 www.sauder.com 414819...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Fasten four ANGLE BRACKETS (3) to the MOLDINGS (E).
  • Page 6 BACK fastened. The unit may collapse. (4 used in this step) Finished edge S u r f a c i t h h o l S u r f a c i t h o u t h o l e Page 6 www.sauder.com 414819...
  • Page 7 Step 3 Fasten the SHELF (G) to the UPPER ENDS (A and B). Use å four BLACK 1-1/2" FLAT HEAD SCREWS (14). BLACK 1-1/2" FLAT HEAD SCREW (4 used in this step) 414819 www.sauder.com Page 7...
  • Page 8 Angled head six HIDDEN CAMS. The arrow must point toward the edge of the board. These edges These surfaces should be even. should be even. These edge should be even. (6 used) These surfaces should be even. Page 8 www.sauder.com 414819...
  • Page 9 BLACK 1/2" FLAT HEAD SCREW LEFT END (H). Use the screws in the HINGES. Fasten a DOOR STOP (4) to the LOWER RIGHT END (J). å Use two BLACK 1/2" PAN HEAD SCREWS (15). DOOR OPENING LEFT 414819 www.sauder.com Page 9...
  • Page 10 S u r f a c i t h h o l S u r f a c i t h o u t h o l e BLACK 1-1/2" FLAT HEAD SCREW (4 used in this step) Page 10 www.sauder.com 414819...
  • Page 11 Now might be a Fasten the LOWER ENDS (H and J) to the SHELF (G). Tighten å good time to refresh four HIDDEN CAMS. your drink. The arrow must point toward the edge of the board. 414819 www.sauder.com Page 11...
  • Page 12 Tap four TACK GLIDES (5) into the LOWER ENDS (H and J) and LEGS (M and N) as shown. å This hole should be left empty for the SAFETY STRAP. NAIL (41 used in this step) Caution Do not stand the unit upright without the BACK fastened. The unit may collapse. Page 12 www.sauder.com 414819...
  • Page 13 Push the RUBBER SLEEVES (12) over the METAL å PINS (11). Insert the METAL PINS into the hole locations of your choice in the ENDS (A, B, H and J). Set the ADJUSTABLE SHELVES (F) onto the METAL PINS. (12 used) 414819 www.sauder.com Page 13...
  • Page 14 Fasten the KNOB (13) to the DOOR (L). Use a BLACK 7/8" å MACHINE SCREW (16). SILVER 1/2" FLAT HEAD SCREW (4 used in this step) BLACK 7/8" MACHINE HEAD SCREW (1 used in this step) Page 14 www.sauder.com 414819...
  • Page 15 Fasten the DOOR (L) to the LOWER END with the HINGE å BRACKETS. Slide the HINGES (12) onto the HINGE BRACKETS on the LOWER END. Secure the DOOR with the mounting screw on the HINGE å BRACKET. See the next step for adjustments. Mounting screw 414819 www.sauder.com Page 15...
  • Page 16 Tighten the screws after making adjustments. To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Page 16 www.sauder.com 414819...
  • Page 17 Follow the instructions included in the KIT to fasten your unit to the wall. å Almost time to celebrate! With a nap. Use the 5/8" screw through the small hole in a bracket and into the back edge of the TOP (C). Small hole 414819 www.sauder.com Page 17...
  • Page 18 This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? 20 lbs. 25 lbs. 25 lbs. 25 lbs. 25 lbs. To cover screws (10 used) 40 lbs. (12 used) To cover HIDDEN CAMS Page 18 www.sauder.com 414819...
  • Page 19 élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE SUPÉRIEURE ....1 EXCENTRIQUE ESCAMOTABLE ....10 Pour contacter Sauder EXTRÉMITÉ GAUCHE SUPÉRIEURE .....1 VIS D'EXCENTRIQUE AVEC TÊTE en ce qui concerne cet EN ANGLE ..............10 DESSUS ................1 élément, faire référence...
  • Page 20 Fixer les CONSOLES DE CHARNIÈRE (8) sur l’EXTRÉMITÉ GAUCHE INFÉRIEURE (H). Utiliser les vis fournies avec les CHARNIÈRES. Fixer un ARRÊT DE PORTE (4) à l’EXTRÉMITÉ DROITE INFÉRIEURE (J). Utiliser deux VIS TÊTE GOUTTE DE SUIF 13 mm NOIRES (15). Page 20 www.sauder.com 414819...
  • Page 21 Serrer les vis après avoir ajusté. Pour ajuster les PORTES vers l'intérieur où vers l'extérieur (profondeur), desserrer la vis de montage un tour et déplacer les PORTES vers l'intérieur ou vers l'extérieur. Serrer la vis de montage après avoir ajusté. 414819 www.sauder.com Page 21...
  • Page 22 EXTREMO DERECHO SUPERIOR ....1 EXCÉNTRICO ESCONDIDO ......10 et conserver le livret pour future référence. EXTREMO IZQUIERDO SUPERIOR ....1 BIELA DE EXCÉNTRICO CON Pour contacter Sauder CABEZA ANGULADA ...........10 PANEL SUPERIOR ............1 en ce qui concerne cet SOPORTE ANGULAR ..........4 DORSO SUPERIOR .............1 élément, faire référence...
  • Page 23 Atornille seis BIELAS DE EXCÉNTRICO (2) dentro de las PATAS (M y N). Empuje seis EXCÉNTRICOS ESCONDIDOS (1) dentro de los EXTREMOS INFERIORES (H y J). Fije las PATAS (M y N) a los EXTREMOS (H y J). Apriete seis EXCÉNTRICOS ESCONDIDOS. 414819 www.sauder.com Page 23...
  • Page 24 NOTA: Asegúrese de clavar ligeramente los CLAVOS dentro de los agujeros que se alinean sobre el ESTANTE (E). Inserte cuatro TACHUELAS (5) en los EXTREMOS INFERIORES (H y J) y en las PATAS (M y N), como se muestra. Page 24 www.sauder.com 414819...
  • Page 25 Para ajustar las PUERTAS hacia atrás o hacia adelante (profundidad), afl oje el tornillo de montaje una vuelta y mueva las PUERTAS hacia el interior o hacia el exterior según sea necesario. Apriete el tornillo de montaje después de hacer los ajustes. 414819 www.sauder.com Page 25...
  • Page 26 • Utilice la correa de seguridad provista para mayor estabilidad. • Los muebles sobrecargados. • Riesgo de lesiones. • Nunca exceda los límites de peso • Los muebles sobrecargados pueden indicados en las instrucciones. romperse. Page 26 www.sauder.com 414819...
  • Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
