Page 6
各部の名称と働き 前面 後面 AC IN 1 〜 端子 3 取っ手取り付け用ネジ穴 DC IN 端子 INTERFACE UNIT PFV-L02 POWER DC STATUS DC IN -AC IN POWER インジケーター 4 ブランクパネル DC STATUS インジケーター 信号用アース 端子 POWER インジケーター AC IN 1 〜 ( 電源入力) 端子...
Page 8
端子に接続する こ と もできます。 レバー AC-550 を使うには 下図のよう に接続し、 AC-550 のPOWERスイ ッチをONにします。 BP-L40/L60A/L90A 電源コード POWER スイッチ : ON AC-550 ( に付属) PFV-L02 D C IN DC IN - A C -AC IN DC OUT DC IN AC-550 AC-550 電源コード ( に付属) AC-DN2A を使うには...
Page 9
Using this unit at a voltage other than 120 V may require the WARNING use of a different line cord or attachment plug, or both. To To prevent fire or shock hazard, do not expose the unit to reduce the risk of fire or electric shock, refer servicing to rain or moisture.
Page 10
WARNING This unit has no power switch. When installing the unit, incorporate a readily accessible disconnect device in the fixed wiring, or connect the power cord to socket-outlet which must be provided near the unit and easily accessible. If a fault should occur during operation of the unit, operate the disconnect device to switch the power supply off, or disconnect the power cord.
Two PFV-L02 units can be horizontally jointed and the PFV-L02 to the board, and the functions of the mounted in a standard 19-inch rack. board are activated. Select the appropriate optional...
Locations and Functions of Parts Rear Panel Front Panel ~AC IN connector Mount holes for handle DC IN connector INTERFACE UNIT PFV-L02 POWER DC STATUS DC IN -AC IN POWER indicator Cover plates DC STATUS indicator U (signal ground) terminal...
Power Preparations This unit can be powered by batteries or AC power. To attach the battery pack Note For details on attaching the BKP-L551, refer to the BKP- If you attach or remove batteries or AC adaptors L551 installation manual. incorrectly, they may fall down and cause body injury.
