Panels and Cables

This section discusses the features and cabling of:
•
•
•

Front Panel

Both the Transmitter and Receiver have identical front panels:
a
Figure 2.
a

DFX 100 Tx Rear Panel

Figure 3.
Front Panel
DFX 100 Tx Rear Panel
DFX 100 Rx Rear Panel
Extron
Extron
DFX 100 Tx and DFX 100 Rx Front Panel
Front Panel LED — lights amber if the unit (transmitter or receiver) is receiving power
from the 12 VDC power supply. The Transmitter LED lights green if the unit is receiving
a TMDS clock signal. The Receiver LED lights green if the unit is receiving an optical
signal.
NOTE: During initialization, the LED may need a few seconds to stabilize to the
correct state.
a
POWER
POWER DFX 100 Tx
DFX 100 Tx
12V
12V
1.0 A MAX
1.0 A MAX
c
OUTPUT
OUTPUT
b
INPUT
INPUT
3 feet (0.91 m) DVI cable
DFX 100 Tx Rear Panel
