DE ' L O N G H I
C OO KING
USERS OPERATING INSTRUCTIONS
INSTALLATION INSTRUCTIONS
D P IN 6 0
TOUCH CONTROL INDUCTION COOKING HOB
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DPIN 60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DeLonghi DPIN 60

Summary of Contents for DeLonghi DPIN 60

  • Page 1 DE ’ L O N G H I C OO KING USERS OPERATING INSTRUCTIONS INSTALLATION INSTRUCTIONS D P IN 6 0 TOUCH CONTROL INDUCTION COOKING HOB...

  • Page 2: Table Of Contents

    CONTENTS Page Number Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Important Safeguards &...

  • Page 3: Introduction

    Dear Customer, Thank you for purchasing a De’ Longhi DPIN 60 induction cooking hob. The safety precautions and recommendations listed below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance.

  • Page 4: Important Safeguards & Recommendations

    IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e.
  • Page 5 manufacturer declines all responsibility for any inconvenience resulting from the inobservance of this condition . • Do not operate your appliance by means of an external timer or separate remote-control system . • Do not carry out cleaning or maintenance operations on the appliance without having previously disconnected it from the electric power supply .
  • Page 6 • WARNING: During use the appliance and its accessible parts become hot; they remain hot for some time after use . Care should be taken to avoid touching heating elements on – the hob . To avoid burns and scalds, young children should be kept –...
  • Page 7 • If the appliance is not fitted with a supply cord and a plug, or with other means for disconnection from the supply mains having a contact separation in all poles that provide full disconnection under overvoltage category III conditions, means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules .
  • Page 8 IMPORTANT WARNING: The induction hob complies with – European Standards for domestic cooking appliances . Therefore it should not interfere with other electronic units . Persons with cardiac pacemakers or any other electrical implants must check with their doctor if they can use an induction cooking system (and check any possible interferences with the implants) .

  • Page 9: Advice For The Installer

    Advice for the installer...

  • Page 10: Installation

    1 - INSTALLATION IMPORTANT: • The appliance is designed and approved for domestic use only and should not be installed in a commercial, semi commercial or communal environment . Your product will not be guaranteed if installed in any of the above environments and could affect any third party or public liability insurances you may have.
  • Page 11 STANDARD INSTALLATION 60cm wide models Fig. 1.1 FLUSH INSTALLATION (MODELS WITHOUT METAL TRIM/S ONLY) If you wish to install the hob flush with the work surface, it is necessary to execute/carry out a milling in the hole of the cut-out as indicated in fig 1 .2 . 60cm wide models Fig.
  • Page 12 This cooktop can be built into a working surface 30 to 50 mm thick and 600 mm deep . In order to install the ceramic hob into the kitchen fixture, a hole with the dimensions shown in figures 1.1 or 1 .2, has to be made, keeping in consideration the following: •...
  • Page 13 FASTENING THE COOKTOP Each cooktop is provided with an installation kit including brackets and screws for fastening the cooktop to benches from 3 to 5 cm thick . The kit includes four metal clips “A” and four self-threading screws “B” (figure. 1.5, 1.5a, 1 .5b) .

  • Page 14: Electrical Section

    2 - ELECTRICAL SECTION IMPORTANT: Installation must be carried out according to the manufacturer’s instructions. Incorrect installation may cause harm and damage to people, animals or property, for which the manufacturer accepts no responsibility. Before carrying out any work on the electrical section of the appliance, it must be disconnected from the mains.
  • Page 15 MODELS SUPPLIED WITHOUT POWER CORD ALREADY FITTED TO THE APPLIANCE CONNECTION OF THE POWER SUPPLY CABLE To connect the feeder cable to the hob it is necessary to carry out the following operations: • Unhook the terminal board cover “A” by inserting a screwdriver into the two hooks “B” (fig.
  • Page 16 Fig. 2.1 220-240 V ac Verde - Giallo Marrone 220...240 V ac 220-240 V ac Green- Yellow Verde - Giallo 380-415 V 2N ac Brown Marrone Verde - Giallo Nero 220-240 V ac 220...240 V ac 220-240 V ac Marrone Blue Verde - Giallo 220...240 V ac...
  • Page 17 MODELS SUPPLIED WITH POWER CORD ALREADY FITTED TO THE APPLIANCE • The cooktop is supplied with a power cord already fitted to the appliance and it is suitable for a single-phase type electrical connection (fig. 2.3). • For the two-phase type electrical connection (fig. 2.4): –...
  • Page 18 connection “220-240 V ac” connection “380-415 V 2N ac” Green - Yellow Green - Yellow Blue and Gray Blue and Gray Black and Brown Black Brown 220-240 V ac 220...240 V ac Fig. 2.3 220-240 V ac 220...240 V ac 380-415 V 2N ac 220...240 V ac 380-415 V 2N ac...

  • Page 20: Advice For The Users

    Advice for the users...

  • Page 21: Features And Technical Data

    1 - FEATURES AND TECHNICAL DATA Electrical insulation Class I COOKING POINTS Induction cooking zone Ø 145 mm - 1200 W (Booster Power: 1600 W) Induction cooking zone Ø 210 mm - 1500 W (Booster Power: 2000 W) Touch controls TOUCH CONTROL DESCRIPTION Note: These figures are indicative...

  • Page 22: Use Of Induction Hob

    2 - USE OF INDUCTION HOB The ceramic hob is fitted with induction cooking zones. These zones, shown by graphic elements painted on the ceramic surface, are controlled by a touch control system . INDUCTION COOKING SYSTEM When your induction hob is switched On and a cooking zone has been selected, the electronic circuits produce induced currents that instantaneously heat the bottom of the pan which then transfers this heat to the food .
  • Page 23 IMPORTANT: Some cookware available on the market has an effective ferromagnetic area which is much smaller than the diameter of the pan itself . Avoid using this cookware because the induction cooktop may not function properly or may be damaged . Pay attention: The pan/coffee pot shall always be centred over the middle of the cooking zone.
  • Page 24 Note: • Each selection (by touching one of the keys) is indicated by an acoustic signal (beep) . • The touch control area is switched off automatically (and a warning beep sounds every 10 seconds): – if one or more keys are touched for more than 10 seconds;...
  • Page 25 AFTERHEAT IN COOKING ZONE/S When switching off a cooking zone (power level “ ”), if the temperature of the zone is too warm to be touched the display will show alternately “ ” and “ ” . Whenever the touch control is switched off, the residual heat is shown by a static “ ”...
  • Page 26 BOOSTER FUNCTION (“FAST HEATING”) This function allows the cooking zone to operate at the “Booster” maximum power (above the nominal power) for maximum 10 minutes; it could be used, for example, to rapidly heat up large amount of water . To activate the “Booster”...
  • Page 27 KEY LOCK SAFETY - CHILD LOCK SAFETY This function locks the “touch-control” keys against unwanted activation . To activate the key-lock press the key the indicator light above the key symbol will light up for a few seconds . Then, if pressing any function key, the light above the key- lock symbol will light up again for a few seconds to indicate that the safety key-lock...
  • Page 28 PROGRAM AUTOMATIC SWITCHING OFF OF ONE COOKING ZONE This function permits to set a timer from “ ” to “ ” minutes for automatic turning Off of the cooking zone . • Select the cooking zone and set the desired power level . •...
  • Page 29 OPERATION TIME LIMIT POWER LEVEL OPERATION COOKING ZONES TIME LIMIT COOKING ZONES Each cooking zone automatically switched OFF after a maximum preset time 10 hours if no operation is performed . The maximum preset time limit depends on the set power level, as illustrated in this 10 hours schedule .
  • Page 30 MAXIMUM POWER MANAGEMENT There are two options to reduce the maximum power limit of the appliance: Option 1 “High range”(high maximum power) The cooktop maximum power limit (7200 W) can be reduced to a minimum of 2800 W, 3500 W or 6000 W . To change the maximum power limit (only within 30 seconds from the electrical connection): •...
  • Page 31 • With the safety key-lock protection deactivated and all the cooking zones off, press (at the same time) the front left cooking zone key, and rear right cooking zone key . • An acoustic signal (beep) will sound and, the current set maximum power limit can be read on the displays of the rear cooking zones (e .g ., rear left zone = “...
  • Page 32 THERMAL PROTECTIONS The induction hob is fitted with safety devices to protect the electronic system and to protect each cooking zone from overheating . • When the touch control reaches an ambient temperature above a preset temperature the heating elements are automatically switched off (the displays show “...
  • Page 33 ERROR CODE ON THE DISPLAY/S error message appears display/s (the display/s show/s “ ” and another character alternating - e .g . “ ” et “ ”, “ ” and “ ”, ..) : Disconnect the cooktop from the mains .

  • Page 34: Cleaning & Maintenance

    3 - CLEANING AND MAINTENANCE GENERAL ADVICE • Before you begin cleaning, you must ensure that the appliance is switched off and disconnected from the electrical power supply. • It is advisable to clean when the appliance is cold . •...

  • Page 35: Guarantee & After Sales Service

    4 - GUARANTEE Your new “De’ Longhi” product comes with 12-month guarantee covering all parts and labour . If your appliance proves to be defective as a result of faulty materials or workmanship during the guarantee period, these parts will be repaired or replaced free of charge . AFTER SALES SERVICE Should you require service, spares or product information and advice: •...
  • Page 36 Descri pt i ons an d ill ustrati ons in this booklet a re giv en as simpl y ind icat ive. T h e ma nuf a ct ur er r es erv es the right, consider ing t he cha ract eri stics o f t he models described here, at any time and without notice, to make eventual necessary mo d ifi cat i on s f or the ir constr ucti on or for com merc ial n eeds.
