Universal vertical power mounting bracket

Advertisement

Universal Vertical Power Mounting Bracket
THANK YOU
Thank you for purchasing the SNE Universal Vertical Power Bracket option by Middle Atlantic
Products. Please read these instructions thoroughly before installing or assembling this product.
PRODUCT FEATURES
• Includes all hardware needed for any SNE series rackrail bracket style.
• Accepts any button mount style power strips (Legrand, Raritan, ServerTech, etc.)
• Mounting holes allows for mounting of PDT, and other Vertical power
Instruction Sheet
SNE Series
100-00070
Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIDDLE ATLANTIC SNE Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND MIDDLE ATLANTIC SNE Series

  • Page 1 Products. Please read these instructions thoroughly before installing or assembling this product. PRODUCT FEATURES • Includes all hardware needed for any SNE series rackrail bracket style. • Accepts any button mount style power strips (Legrand, Raritan, ServerTech, etc.) • Mounting holes allows for mounting of PDT, and other Vertical power 100-00070...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS • Read these instructions. • Heed all warnings. • Clean only with dry cloth. • Keep these instructions. • Follow all instructions. • Only use attachments/accessories specified by the manufacturer. WARNING: A warning alerts you to a situation that could result in serious personal injury or death. WARNING: Middle Atlantic Products, Inc.
  • Page 3 SUPPLIED COMPONENTS AND HARDWARE (3x) (3x) 10-32 x 1¾” Spring Nut Flathead Phillips Screw (4x) Cage Nut REQUIRED TOOLS • #2 Phillips Screwdriver WARNING: Use tools with caution and follow all necessary safety protocols. AVERTISSEMENT: Utiliser des outils avec prudence et suivre tous les protocoles de sécurité...
  • Page 4 INSTALLING UNIVERSAL VERTICAL POWER BRACKET 42 RU 1. Slide a spring nut (B) into the top unistrut channel on one side of your enclosure’s interior as shown. (FIGURE B) 2. Use a 10-32x 1¾" Flathead Phillips screw (C) through a hole in the top location on your universal vertical power bracket and into the spring nut (B).
  • Page 5 INSTALLING UNIVERSAL VERTICAL POWER BRACKET 45 RU 1. Hook the top of the Universal Vertical Power Bracket to the top unistrut on the enclosure. (FIGURE C) 2. Slide a spring nut (B) into the second unistrut channel on one side of your enclosure’s interior as shown.
  • Page 6 Voice: 613-836-2501 - Fax: 613-836-2690 - ca.middleatlantic.com - customerservicecanada@middleatlantic.ca Middle Atlantic EMEA Technical Support Voice: +31 (0) 495 726002 - av.emea.middleatlantic.support@legrand.com Factory Distribution United States: New Jersey, California, Illinois - Canada: Ontario - The Netherlands: Weert At Middle Atlantic Products we are always listening. Your comments are welcome.
