Rohm LAPIS ML610Q411 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Dear customer
st
LAPIS Semiconductor Co., Ltd. ("LAPIS Semiconductor"), on the 1
day of October,
2020, implemented the incorporation-type company split (shinsetsu-bunkatsu) in which
LAPIS established a new company, LAPIS Technology Co., Ltd. ("LAPIS
Technology") and LAPIS Technology succeeded LAPIS Semiconductor's LSI business.
Therefore, all references to "LAPIS Semiconductor Co., Ltd.", "LAPIS Semiconductor"
and/or "LAPIS" in this document shall be replaced with "LAPIS Technology Co., Ltd."
Furthermore, there are no changes to the documents relating to our products other than
the company name, the company trademark, logo, etc.
Thank you for your understanding.
LAPIS Technology Co., Ltd.
October 1, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAPIS ML610Q411 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rohm LAPIS ML610Q411

Summary of Contents for Rohm LAPIS ML610Q411

  • Page 1 Dear customer LAPIS Semiconductor Co., Ltd. ("LAPIS Semiconductor"), on the 1 day of October, 2020, implemented the incorporation-type company split (shinsetsu-bunkatsu) in which LAPIS established a new company, LAPIS Technology Co., Ltd. (“LAPIS Technology”) and LAPIS Technology succeeded LAPIS Semiconductor’s LSI business. Therefore, all references to "LAPIS Semiconductor Co., Ltd.", "LAPIS Semiconductor"...
  • Page 2 FEUL610Q411-05 ML610Q411/Q412 User’s Manual Issue Date: July. 13, 2015...
  • Page 3 11) Please use the Products in accordance with any applicable environmental laws and regulations, such as the RoHS Directive. For more details, including RoHS compatibility, please contact a ROHM sales office. LAPIS Semiconductor shall have no responsibility for any damages or losses resulting non-compliance with any applicable laws or regulations.
  • Page 4 ML610Q411/Q412 User’s Manual Cover Preface This manual describes the operation of the hardware of the 8-bit microcontroller ML610Q411/ML610Q412. The following manuals are also available. Read them as necessary. nX-U8/100 Core Instruction Manual Description on the basic architecture and the each instruction of the nX-U8/100 Core MACU8 Assembler Package User’s Manual Description on the method of operating the relocatable assembler, the linker, the...
  • Page 5 ML610Q411/Q412 User’s Manual Cover Notation Classification Notation Description ♦ Numeric value xxh, xxH Indicates a hexadecimal number. x: Any value in the range of 0 to F Indicates a binary number; “b” may be omitted. x: A value 0 or 1 ♦...

  • Page 6: Table Of Contents

    ML610Q411/ML610Q412 User’s Manual Contents Table of Contents Chapter 1 Overview................................. 1-1 Features ............................... 1-1 Configuration of Functional Blocks ......................1-5 1.2.1 Block Diagram of ML610Q411 ......................1-5 1.2.2 Block Diagram of ML610Q412 ......................1-6 Pins ................................1-7 1.3.1 Pin Layout ............................1-7 1.3.1.1 Pin Layout of ML610Q411 LQFP Package..................
  • Page 7 ML610Q411/ML610Q412 User’s Manual Contents 4.2.6 Block Control Register 2 (BLKCON2)....................4-7 4.2.7 Block Control Register 3 (BLKCON3)....................4-8 4.2.8 Block Control Register 4 (BLKCON4)....................4-9 Description of Operation........................... 4-11 4.3.1 Program Run Mode ........................... 4-11 4.3.2 HALT Mode ............................. 4-11 4.3.3 STOP Mode ............................
  • Page 8 ML610Q411/ML610Q412 User’s Manual Contents 6.3.2.2 External Clock Input Mode ......................6-9 6.3.2.3 Operation of High-Speed Clock Generation Circuit ..............6-10 6.3.3 Switching of System Clock ....................... 6-12 Specifying port registers ........................... 6-14 6.4.1 Functioning P21 (OUTCLK) as the high speed clock output ............6-14 6.4.2 Functioning P22 (LSCLK) as the low speed clock output ..............
  • Page 9 ML610Q411/ML610Q412 User’s Manual Contents 10.2.1 List of Registers ..........................10-3 10.2.2 Timer 0 Data Register (TM0D) ......................10-4 10.2.3 Timer 1 Data Register (TM1D) ......................10-5 10.2.4 Timer 2 Data Register (TM2D) ......................10-6 10.2.5 Timer 3 Data Register (TM3D) ......................10-7 10.2.6 Timer 0 Counter Register (TM0C) ....................
  • Page 10 ML610Q411/ML610Q412 User’s Manual Contents 13.1.3 List of Pins ............................13-2 13.2 Description of Registers ..........................13-3 13.2.1 List of Registers ..........................13-3 13.2.2 Serial Port Transmit/Receive Buffers (SIO0BUFL, SIO0BUFH) ............ 13-4 13.2.3 Serial Port Control Register (SIO0CON) ..................13-5 13.2.4 Serial Port Mode Register 0 (SIO0MOD0) ..................
  • Page 11 ML610Q411/ML610Q412 User’s Manual Contents 15.3.1.1 Start Condition ..........................15-9 15.3.1.2 Restart Condition ........................... 15-9 15.3.1.3 Slave Address Transmit Mode ....................... 15-9 15.3.1.4 Data Transmit Mode ........................15-9 15.3.1.5 Data Receive Mode ........................15-9 15.3.1.6 Control Register Setting Wait State ....................15-9 15.3.1.7 Stop Condition ..........................
  • Page 12 ML610Q411/ML610Q412 User’s Manual Contents Chapter 19 19. Port 2 ................................19-1 19.1 Overview..............................19-1 19.1.1 Features ............................. 19-1 19.1.2 Configuration ............................ 19-1 19.1.3 List of Pins ............................19-1 19.2 Description of Registers ..........................19-2 19.2.1 List of Registers ..........................19-2 19.2.2 Port 2 Data Register (P2D) .......................
  • Page 13 ML610Q411/ML610Q412 User’s Manual Contents 22.2.2 Port A Data Register (PAD)......................22-3 22.2.3 Port A Direction Register (PADIR) ....................22-4 22.2.4 Port A Control Registers 0, 1 (PACON0, PACON1) ............... 22-5 22.3 Description of Operation........................... 22-7 22.3.1 Input/Output Port Functions......................22-7 Chapter 23 23.
  • Page 14 ML610Q411/ML610Q412 User’s Manual Contents 25.2.5 SA-ADC Result Register 1H (SADR1H) ..................25-5 25.2.6 SA-ADC Control Register 0 (SADCON0) ..................25-6 25.2.7 SA-ADC Control Register 1 (SADCON1) ..................25-7 25.2.8 SA-ADC Mode Register 0 (SADMOD0) ..................25-8 25.3 Description of Operation........................... 25-9 25.3.1 Settings of A/D Conversion Channels ....................
  • Page 15 ML610Q411/ML610Q412 User’s Manual Contents Appendixes Appendix A Registers ............................A-1 Appendix B Package Dimensions ........................B-1 Appendix C Electrical Characteristics .........................C-1 Appendix D Application Circuit Example ......................D-1 Appendix E Check List ............................E-1 Revision History Revision History ..............................R-1 FEUL610Q411 Contents – 10...

  • Page 16: Overview

    Chapter 1 Overview...
