Continuous Radar Level Sensor (80GHz)
Basic Setup
STEPS
Home Screen
Press
Key
OK
Main Menu
Press
Key
OK
User Parameters
Press
Key
OK
Basic Setup
Press
Key
OK
Range
Press
Key
OK
Setting 4mA / 20mA
Press
Key
OK
Blind / ShowType
Press
Key
OK
Damping Time
Press
Key 3 Time
ESC
24-0167
© Icon Process Controls Ltd.
DISPLAY
When Power is on, Display will Show the Home Screen
0.578m
Press
Main Menu
User Para.
Select User Parameter and Press
Factory Para.
User Para.
Basic Setup
Select Basic Setup and Press
Measure Setup
Backup Para.
Basic Setup
Range:
10000
mm
Select Range and Press
Offset:
0
mm
Pos 4ma:
0
mm
Basic Setup
Range:
10000
mm
Change Range Value Using
Offset:
0
mm
Pos 4ma:
0
mm
Basic Setup
Set 4mA (Low Level) & 20mA (High Level) Value
Pos 4ma:
0
mm
and Press
Pos 20ma:
9000
mm
Blind:
05
mm
Basic Setup
Set the Blind Distance and Press
Blind:
10
mm
ShowType: Level
Set ShowType : Level / Distance. Press
Damping Time: 10
Basic Setup
Set the Damping time. Press
Damping Time: 10
DeviceID : 1
Press
BaudRate: 9600
Use
&
OPERATION
to go to Main Menu
OK
OK
OK
OK
&
to confirm.
OK
OK
to Confirm
OK
3 time to Show Home Screen
ESC
to change Selection / Values
and Press
OK
OK
9
