ProScan ® 3 Series
Continuous Radar Level Sensor (80GHz)
ProScan 3 to TVL Display Connection
®
TVL Displays
R
A L R 1 R 2
ESC
ENTER
MENU
ProScan ® 3 Blind to
TVL Display
Connection
Red
Positive (+)
24-0167 © Icon Process Controls Ltd.
ProScan ® 3
Black
Negative (-)
PP Body
Red wire Terminal 8
Black wire Terminal 11
Red wire Terminal 8
Black wire Terminal 11
316 SS Body
13 12 11 10 09 08 07 06 05 04 03 02
Power Supply 120VAC
Terminal 1 & 2
13 12 11 10 09 08 07 06 05 04 03 02
Power Supply 120VAC
Terminal 1 & 2
01
01
6
