Dimensions - ICON LevelPro ProScan 3 Series Operating Manual

ProScan ® 3 Series
Continuous Radar Level Sensor (80GHz)
Basic Parameters
23LD12184
Range(inch) 120.00
Migration Amount(inch) 0.0
0.0
4mA Location(inch)
110.00
20mA Location(inch)
Blind Area(inch) 4.00
10
Damping Time
Device Address 1
9600
Baud Rate
READ SET BACKUP RESTORE
Back to
Setting Menu

Dimensions

123mm
20mm
24-0167 © Icon Process Controls Ltd.
Set
23LD12184
Basic Parameters
Advanced Parameters
System Settings
Home Curve Set
Click Home Button
to Show Home Screen
Ø.73mm
1½" NPT
Display Sensor
Home
23LD12184
Level(inch) 35.7873
20 mA
Distance(inch) 84.2124
Current(mA) 8.771
Percentage(%) 29.82
Running State 0
Update Time 2023/11/21 16:29:36
4 mA
Home Curve Set
96mm
10mm
Measurement
Location
100%
Max Config
Range
0%
Ø.70mm
2" NPT
Blind Sensor
12
