3. Place two more Transparent GTL's over the middle and upper 1/3 sections of the Volume Bar.

Assigning the Proper RC68 IR Codes to the Transparent GTL's

1. In the Palette Editor Window click the RC68 Tab.
2. Click the Options Tab on the Virtual RC68 Palette and choose MRC88 from the Xantech Model drop-
down.
3. Click the RC68 Remote Tab on the Virtual RC68.
4. In the SPLCD System Window, select the Transparent GTL placed on the lower 1/3 of the Volume Bar.
5. Click the [80] Button on the Virtual RC68. In the Macro Command List Window you should see the
command: 'C (A8,10) (Xantech – MRC88)'.
6. Repeat Steps 4-5 with the RC68 [48] Command associated with the middle Transparent GTL and the
[10] Command associated with the upper Transparent GTL as shown above.
