Input

When Input is selected in the Line Input Role Block and a 5 to 30V DC signal is present on the Status
Terminal on the rear of the SPLCD, the following event/actions can be triggered:
1. The Status LED on the SPLCD Front Panel will turn ON [Requires LED Track to be selected, (check
mark)].
2. Initiate a Sense Trigger Macro (if one is associated to the System Window/Sense Tab/ON Button).
3. Utilize Intelligent Power Management (if selected at: System Window/Sense Tab/Intelligent Power
Management).
NOTE: Items 1&2 or 1&3 may be programmed to occur simultaneously.

Output

When Output is selected in the Line Input Role Block, the Status Terminal becomes a switchable12V DC
Output. When the Internal Command: Set Line Status/ON is placed under a GTL and that button is pressed,
the Status Terminal outputs 12V DC. When the Internal Command: Set Line Status/OFF is placed under a
GTL and that button is pressed, the Status Terminal outputs 0V DC. This can be utilized to control an external
device via a 12V trigger when an appropriately configured GTL is pressed (i.e. Control a Projection Screen, a
Lift, Drapes or an amplifier with a 12V DC Control Input).
Note: The Status Output is rated at 15mA maximum.

BACKLIGHT SETTINGS

This sets the LCD Backlight to stay ON for a specified amount of time after the display is last touched. The
Backlight can be set to stay ON from 1-30 seconds in 1 second increments, 1-30 minutes in 1 minute
increments or Always ON.
NOTE: The internal IR receiver is disabled whenever the Backlight is ON to avoid interference. Therefore if
Always ON is selected, the IR Receiver will not be active.

DISPLAY ORIENTATION

The LCD Display needs to be configured for the proper viewing angle according to the position it will be
installed with regard to the user. (Figure 50)
Up
Select this setting if the SPLCD will be installed at a height equal to or above the user's eye level. (IR Sensor
on the right side, Rear Panel in normal orientation.)
Down
Select this setting if the SPLCD will be installed at a height equal to or below the user's eye level. (IR Sensor
on the left side, Rear Panel upside down. If the SPLCD is not oriented as described, the graphics will appear
upside down.)
