MORTEX G18D Series Installation Manual

Downflow only gas furnace
Hide thumbs Also See for G18D Series:
Table of Contents

Advertisement

Quick Links

Download this manual
DOWNFLOW ONLY GAS FURNACE
SIZES 60, 70, 77, 90
MODELS: G18D SERIES
For installation only in HUD manufactured homes per Construction Safety 24 CFR Part 3280
1 - Safety .....................................................................................................................2
2 - General Information ........................................................................................6
3 - Furnace Ductwork and Filters ......................................................................8
4 - Gas Supply and Valve Connections ......................................................... 11
5 - Line and Low Voltage Wiring ..................................................................... 17
1 - Furnace Dimensions .........................................................................................6
2 - Combustible Floor Base Assembly ..............................................................9
3 - Duct Connector Dimensions .........................................................................9
4 - Duct Connector and Floor Base Assembly ...............................................9
5 - Duct Connector Depths ..................................................................................9
6 - Air Distribution System - Single Trunk Duct ....................................... 10
7 - Air Distribution System - Double Trunk Duct ................................................ 10
8 - Air Distribution Systems - Graduated trunk duct ........................................ 10
10 - Outdoor Fresh Air Intake Knockout ......................................................... 11
12 - White Rodgers Gas valve ................................. ........................................... 12
13 - Burner Assembly................................ ............................................................ 13
14 - Component Locations................................. ................................................. 17
1 - Model Number Nomenclature ...........................................................................
................................................................................... 15
Manufactured and Distributed by:
The following list includes important facts and information regarding this gas furnace.
1. Furnace is rated at 115 VAC at 60 Hz.
2. Furnace is available in "Heating Only" or "A/C Ready" configurations.
3. Furnace is designed for use with cooling only or heat pump systems when a cooling coil cabinet and indoor coil is used. A/C
ready models are furnished with a cooling coil cabinet. The appropriate indoor coil must be selected and ordered separately.
4. A hold-down strap is furnished with furnace.
5. This furnace is designed for downflow applications only.
6. This furnace must not be operated with the control box cover or front access panels removed.
7. This furnace is certified by ETL for use in the United States only.
MORTEX PRODUCTS INC
INSTALLATION MANUAL
LIST OF SECTIONS
LIST OF FIGURES
LIST OF TABLES
............................................................7
........................................................... 14
............................................................... 16
......................................... 16
........................ 16
............................ 16
................................ 18
CONTACT INFORMATION
Mortex Products Inc
501 Terminal Rd
Fort Worth, TX 76106
SAVE THIS MANUAL FOR FUTURE REFERENCE
501 TERMINAL RD FORT WORTH, TX 76106
6 - Furnace Combustion Air and Vent System ............................................20
8 - Blower Performance ......................................................................................31
9 - Wiring Diagrams .............................................................................................32
20 - Roof Jack Mounting Collars - Top of Furnace .....................................21
21 - Roof Jack Indoor Extension Pipes ...........................................................21
22 - Roof Jack Outdoor Extension Pipes.........................................................21
23 - Roof Jack Slope Saddle ................................................................................22
24 - Roof Jack Crown Assembly ........................................................................22
25 - Combustion Air Path Through Furnace Casing ...................................23
26 - Flue Vent & Combustion Air For Furnace ...............................................23
27 - Home Layout & Vent Clearances ..............................................................24
28 - Typical Roof Jack Installation .....................................................................25
29 - White Rodgers Gas Valve .............................................................................27
30 - Measuring Inlet (Supply) Gas Pressure ...................................................27
31 - Measuring Outlet (Manifold) Gas Pressure ...........................................27
32 - Integrated Control Board ............................................................................29
33 - Wiring Diagram Heating Only Models....................................................32
34 - Wiring Diagram A/C Ready Models .........................................................33
6
....................................................................................................
................................................................................ 25
............................................................... 27
........................................................................... 27
.......................................... 28
....................................... 28
............................................................................ 31
www.mortx.com
20
24
.............. 29
Page 1
