MORTEX 97-F Series Installation Manual

INSTALLATION MANUAL
DOWNFLOW / HORIZONTAL COIL CABINET
DOWNFLOW LOUVERED DOOR ASSEMBLY
MODELS: 97-F SERIES
1 – General
2 – Safety
1 – Cooling Coil Cabinet Dimensions
2 – Return Air Grille Frame Assembly
3 – Return Air Grille
1 – Coil Cabinet Models Nomenclature
SECTION I: GENERAL
The following list includes important facts and information
regarding the louvered door frame assembly for your coil
cabinet and its inclusions.
1. A/C coil cabinet designed to be attached to an electric
furnace equipped with blower for A/C or Heat Pump
operation.
2. A/C coil cabinets are available heights are shown in
Table 2.
3. Frame and Grille assembly is available in an 18 inch
height and a 24 inch height.
4. Frame and Grille assembly does not have an air filter.
Air filters are placed on top of the cooling coil. Refer
to Figure 4.
NOTE: This furnace and its components listed on the A/C and
Heat Pump equipment sticker were listed in combination as a
system by ETL for the United States.
MORTEX PRODUCTS INC
LIST OF SECTIONS
1 3 – Louvered Door Frame Assembly Installation
2 4 – Coil Cabinet Installation
LIST OF FIGURES
1 4 – "A" Coil Filters
4 5 – Coil Cabinet Door Mounting Bracket
Coil Cabinet Door Mounting Bracket Location
4 6 –
LIST OF TABLES
3 2 – Coil Cabinet and Return Frame Assembly Models
Figure 1: Cooling Coil Cabinet Dimensions
FORT WORTH, TX 76106
3
5
4
5
5
3
Page 1
